Machine Type: Battery Operated
Solution Tank Capacity: 13-Gallon
Recovery Tank Capacity: 15-Gallon
Cleaning Path: 20”
Pad Drive Diameter: Single 20”
Pad Drive Speed: 200 rpm
Pad Pressure: 50 lbs
Pad Drive Motor: .75 hp
Vacuum Motor: 2-stage
Squeegee Width: 28”
Voltage: 24 volts
Waterlift: 55”
Charging System: 110V 9 amp built-in charger
Sound Level (dBA): 69 dBA
Batteries (not included): 2-12V, 105 Amp Hr. or 130 Amp Hr. Batteries
Run Time Per Charge: 3.5 Hr. estimated (130 Amp Hr.)
Productivity Rate: 21,000 sq. ft./hr.
Wheels: Non-marking Grey
Dimensions: 53L x 22.5W x 38H inches
Weight: 280 lbs (with batteries)
Triple S (SSS) PANTHER 20B Parts and Support
the panther 20b auto scrubber features a single 20-inch disk. this powerful, battery operated unit, efficiently cleans 21,000 square feet per hour, and runs for an estimated 3 and a half hours per charge. the panther 20b is equipped with a sturdy housing, easy-touse controls and a heavy-duty cast aluminum squeegee assembly, for years of dependable and productive service. this highly maneuverable scrubber has a 20” cleaning path and large solution and recovery tanks for increased productivity.
machine type: battery operated
solution tank capacity: 13-gallon
recovery tank capacity: 15-gallon
cleaning path: 20”
pad drive diameter: single 20”
pad drive speed: 200 rpm
pad pressure: 50 lbs
pad drive motor: .75 hp
vacuum motor: 2-stage
squeegee width: 28”
voltage: 24 volts
waterlift: 55”
charging system: 110v 9 amp built-in charger
sound level (dba): 69 dba
batteries (not included): 2-12v, 105 amp hr. or 130 amp hr. batteries
run time per charge: 3.5 hr. estimated (130 amp hr.)
productivity rate: 21,000 sq. ft./hr.
wheels: non-marking grey
dimensions: 53l x 22.5w x 38h inches
weight: 280 lbs (with batteries)
machine type: battery operated
solution tank capacity: 13-gallon
recovery tank capacity: 15-gallon
cleaning path: 20”
pad drive diameter: single 20”
pad drive speed: 200 rpm
pad pressure: 50 lbs
pad drive motor: .75 hp
vacuum motor: 2-stage
squeegee width: 28”
voltage: 24 volts
waterlift: 55”
charging system: 110v 9 amp built-in charger
sound level (dba): 69 dba
batteries (not included): 2-12v, 105 amp hr. or 130 amp hr. batteries
run time per charge: 3.5 hr. estimated (130 amp hr.)
productivity rate: 21,000 sq. ft./hr.
wheels: non-marking grey
dimensions: 53l x 22.5w x 38h inches
weight: 280 lbs (with batteries)
