This 27" scrubber packs in big features that keep downtime to a minimum, like an easily accessible design that allows squeegees and brushes to be changed in seconds and the convenient squeegee button that provides the ability to do a double scrub without exiting the machine. The intuitive controls reduces the training time for even your most inexperienced employees. Clean anytime with quiet operation of less than 80 dBA and continue to clean up for up to four hours with the optional battery.
MACHINE DIMENSIONS
Dimensions (LxWxH) 61” x 30” x 55” (without squeegee)
Net Weight (Empty) 760 lbs (with battery)
470 lbs (without battery)
Sound Level <70 dB
TANK SYSTEM
Solution Capacity 26.4 gal
Recovery Tank Capacity 28 gal
Tank Construction Polyethylene
Sink Fill Hose Yes
Inline Solution Filter Yes
SCRUBBING SYSTEM
Squeegee Width 34"
Cleaning Path 27” (2 x 14"
Brush Pressure 126 lbs
Brush Motor 2 x .5 hp
Brush RPM 160
Productivity Per Hour (Theoretical Max) 50,698 sq ft
VACUUM MOTOR SYSTEM
Vacuum Motor Power .65 hp
Vacuum Motor Water Lift 50"
Silent Mode Yes
DRIVE SYSTEM
Drive Type Self-Propelled
Motor Horsepower .7 hp
Turning Radius 65"
BATTERY & CHARGING SYSTEM
System Voltage 24 V
Run Time 3-4 hrs
Charger Type On-board
Battery Types Lead acid or AGM
Tornado Industries BDSO 27/28 Parts and Support
the tornado 27" stand-on scrubber combines the comfort and efficiency of a rider with the practicality of a small scrubber. this stand-on model can be maneuvered easily around obstacles with superior control and efficiently covers up to 50,698 sq ft/hr without having to take a single step, making it great for large facilities. the 126 ls of down pressure of 160 rpm of agitation maximizes soil removal, while the water recovery system provides a streak-free clean that leaves floors dry and safe.
this 27" scrubber packs in big features that keep downtime to a minimum, like an easily accessible design that allows squeegees and brushes to be changed in seconds and the convenient squeegee button that provides the ability to do a double scrub without exiting the machine. the intuitive controls reduces the training time for even your most inexperienced employees. clean anytime with quiet operation of less than 80 dba and continue to clean up for up to four hours with the optional battery.
machine dimensions
dimensions (lxwxh) 61” x 30” x 55” (without squeegee)
net weight (empty) 760 lbs (with battery)
470 lbs (without battery)
sound level <70 db
tank system
solution capacity 26.4 gal
recovery tank capacity 28 gal
tank construction polyethylene
sink fill hose yes
inline solution filter yes
scrubbing system
squeegee width 34"
cleaning path 27” (2 x 14"
brush pressure 126 lbs
brush motor 2 x .5 hp
brush rpm 160
productivity per hour (theoretical max) 50,698 sq ft
vacuum motor system
vacuum motor power .65 hp
vacuum motor water lift 50"
silent mode yes
drive system
drive type self-propelled
motor horsepower .7 hp
turning radius 65"
battery & charging system
system voltage 24 v
run time 3-4 hrs
charger type on-board
battery types lead acid or agm
this 27" scrubber packs in big features that keep downtime to a minimum, like an easily accessible design that allows squeegees and brushes to be changed in seconds and the convenient squeegee button that provides the ability to do a double scrub without exiting the machine. the intuitive controls reduces the training time for even your most inexperienced employees. clean anytime with quiet operation of less than 80 dba and continue to clean up for up to four hours with the optional battery.
machine dimensions
dimensions (lxwxh) 61” x 30” x 55” (without squeegee)
net weight (empty) 760 lbs (with battery)
470 lbs (without battery)
sound level <70 db
tank system
solution capacity 26.4 gal
recovery tank capacity 28 gal
tank construction polyethylene
sink fill hose yes
inline solution filter yes
scrubbing system
squeegee width 34"
cleaning path 27” (2 x 14"
brush pressure 126 lbs
brush motor 2 x .5 hp
brush rpm 160
productivity per hour (theoretical max) 50,698 sq ft
vacuum motor system
vacuum motor power .65 hp
vacuum motor water lift 50"
silent mode yes
drive system
drive type self-propelled
motor horsepower .7 hp
turning radius 65"
battery & charging system
system voltage 24 v
run time 3-4 hrs
charger type on-board
battery types lead acid or agm
Parts
Can't find what you need? Click here or call 1-800-USA-CLEAN
In the market for a new machine? You can find quality new and reconditioned floor care equipment at one of our vendor partners:
Need a professional? We offer service both virtually and in person.
Learn more
Diagrams
- View all diagrams
- Wiring Diagram- Battery Charger from SN 11001537-17001538
- -Commonly Asked For Parts
- Battery Charger Assembly
- Battery, Brushes, and Charger
- Brush Base Assembly
- Brush Base Control Assembly
- Brush Base Transmission Assembly
- Control Panel Assembly
- Drive Wheel Control Assembly
- Electrical Layout
- Foot Board Assembly
- Frame Assembly
- Lower Cover Assembly
- Pad Holders
- Pads
- Rear Cover Assembly
- Rear Wheel Assembly
- Recovery Tank Assembly
- Solution Tank Assembly
- Squeegee Assembly
- Squeegee Control Assembly
- Steering Wheel Assembly
- Vacuum Assembly
- Water Filter Assembly
- Water Valve Assembly
- Wiring Diagram
- Wiring Diagram After SN 17001537
- Wiring Diagram Between SN 11001537 and SN 17001538
- Wiring Diagram- Battery Charger after SN 17001537
- Wiring Diagram-Battery Charger
