WRANGLER 2016B

20

• Parts
• Diagrams
• Bulletins
• Docs

Features a 20" scrubbing path, tight turning radius and rugged polyethylene construction. Quieter operation mean extended use in work environments.

•The wheel-drive unit features twist grip propulsion, just like its Wrangler "Big Brothers".
•The built-in battery tray drain permits quick clean up in the case of battery acid spills inside the battery tray.
•The 32" wide urethane squeegee picks up in forward and reverse.
•Mid-mounted wheels provide superior maneuverability and a tight-turning radius.
•The percolator helps break down recovered foam that might otherwise damage the vacuum motor.
•The polyethylene body is non-corrosive and will withstand the toughest professional use .
•The solution-fill port is now on the outside of the Wrangler 2016- no need to open up the machine to add solution. Since the fill port and drain hose are both at the front of the unit, there is no need to jockey the machine around in the janitor's closet.
•A powerful 3/4 HP gear motor rotates the scrub brush at a steady 200 RPM. A solenoid automatically shuts off the solution flow when the brushes stop, preventing accidental flooding during pauses in operation.
•The scrub head tilts up for easy pad and brush changes. The scrub head is also offset for close edge cleaning.
•All Wrangler 2016 models are available with a curved squeegee assembly. Ideal for industrial applications, the curved squeegee funnels water and debris into the center, traps it and vacuums it in one pass. The durable gum rubber blades are resistant to damage from stripping solutions.
•Included is a wet pick up kit. Connect the hose to your Wrangler 2016 and you are ready to vacuum those hard to reach areas, like corners where no automatic scrubber can go.
•When not in use, the tube handle can be easily dismantled and stored right on top of the Wrangler for easy access.
•A special cargo net at the back of the unit is ideal storage for spray bottles and the squeegee tool when not in use.
•Another unique feature of the Wrangler 2016 is our breakaway squeegee assembly. If the wide, 32" squeegee is inadvertently caught on a fixture, the squeegee assembly pulls off its holding bracket at the rear of the machine. It does not bend or break. It does not damage fixtures. Reconnecting it is as simple as hand tightening two control knobs. This breakaway feature keeps the Wrangler 2016 working when other machines must be taken off the job to be repaired.

Scrubbing path: 20"
Squeegee path: 32", swing type
Vacuum motor: 3 stage, bypass tangential discharge, 24V, .75 hp
Closed water lift: 58"
Brush drive motor: Permanent magnet, gear motor, 24V, .75 HP
Drive: Self-propelled through brush/pad
Construction: Rotocast polyethylene body, mounted on steel frame
Wheels: (2) 8" x 4" dia w/slip grip tread
Casters: 4" dia x 2" ball bearing swivel caster
Brush/pad speed: 200 RPM
Brush pressure: Floating: 60 lbs, Lock down: 80 lbs
Tool kit: 2-pc wand w/ 7 ft hose and hose connector and 17" squeegee tool
Cleaning rate per charge: obstructed: 7,263 ft; Unobstructed: 9,684ft
Run time per charge: up tp 4.6 charge
Weight: machine only: 177 lbs, w/ batteries and driver: 480 lbs
