• Easy-to-use, fingertip controls
• On-board battery charger
• Parabolic squeegee for easy and complete solution pick-up
• Free online training video shows use and care of scrubber for optimal performance
RUGGED
• 12-year housing warranty
• 5-year warranty on motors
• Heavy-duty, cast aluminum squeegee assembly
• Engineered to withstand heavy, daily use in commercial applications such as schools, office buildings, and medical facilities
AFFORDABLE
• Best value in the industry
• Charger, pad driver, and squeegee assembly included
• High cleaning productivity rate
• Extra set of squeegee blades included and stored on-board
• Backed by the most extensive, hassle-free warranty in the business
Cleaning Path: 20 in
Solution Tank: 13 gal
Recovery Tank: 15 gal
Pad Size: 20 in
Pad Pressure: 50 lbs
Squeegee, Easy to Remove: 28 in
Cleaning Productivity (Max): 21,000 ft2/hr
Drive System: Pad-assist drive
Wheels, Non-marking Grey: (2) 8 in
Brush Motor, rpm Speed: .75 hp, 200 rpm
Vacuum Motor, Waterlift: 2-stage, 55 in waterlift
Optional 130 Batteries: Two 12V, 130 amp/hr
Optional 105 Batteries: Two 12V, 105 amp/hr
Charger, On-board: 9 amp
Run Time per Charge Approx.: 3-3.5 hrs
Weight without Batteries: 210 lbs
Ship Weight w/o Batteries: 320 lbs
Dimensions (L x W x H): 53.5 in x 22 in x 38.5 in
Viper FANG 20 Parts and Support
simple
• easy-to-use, fingertip controls
• on-board battery charger
• parabolic squeegee for easy and complete solution pick-up
• free online training video shows use and care of scrubber for optimal performance
rugged
• 12-year housing warranty
• 5-year warranty on motors
• heavy-duty, cast aluminum squeegee assembly
• engineered to withstand heavy, daily use in commercial applications such as schools, office buildings, and medical facilities
affordable
• best value in the industry
• charger, pad driver, and squeegee assembly included
• high cleaning productivity rate
• extra set of squeegee blades included and stored on-board
• backed by the most extensive, hassle-free warranty in the business
cleaning path: 20 in
solution tank: 13 gal
recovery tank: 15 gal
pad size: 20 in
pad pressure: 50 lbs
squeegee, easy to remove: 28 in
cleaning productivity (max): 21,000 ft2/hr
drive system: pad-assist drive
wheels, non-marking grey: (2) 8 in
brush motor, rpm speed: .75 hp, 200 rpm
vacuum motor, waterlift: 2-stage, 55 in waterlift
optional 130 batteries: two 12v, 130 amp/hr
optional 105 batteries: two 12v, 105 amp/hr
charger, on-board: 9 amp
run time per charge approx.: 3-3.5 hrs
weight without batteries: 210 lbs
ship weight w/o batteries: 320 lbs
dimensions (l x w x h): 53.5 in x 22 in x 38.5 in
• easy-to-use, fingertip controls
• on-board battery charger
• parabolic squeegee for easy and complete solution pick-up
• free online training video shows use and care of scrubber for optimal performance
rugged
• 12-year housing warranty
• 5-year warranty on motors
• heavy-duty, cast aluminum squeegee assembly
• engineered to withstand heavy, daily use in commercial applications such as schools, office buildings, and medical facilities
affordable
• best value in the industry
• charger, pad driver, and squeegee assembly included
• high cleaning productivity rate
• extra set of squeegee blades included and stored on-board
• backed by the most extensive, hassle-free warranty in the business
cleaning path: 20 in
solution tank: 13 gal
recovery tank: 15 gal
pad size: 20 in
pad pressure: 50 lbs
squeegee, easy to remove: 28 in
cleaning productivity (max): 21,000 ft2/hr
drive system: pad-assist drive
wheels, non-marking grey: (2) 8 in
brush motor, rpm speed: .75 hp, 200 rpm
vacuum motor, waterlift: 2-stage, 55 in waterlift
optional 130 batteries: two 12v, 130 amp/hr
optional 105 batteries: two 12v, 105 amp/hr
charger, on-board: 9 amp
run time per charge approx.: 3-3.5 hrs
weight without batteries: 210 lbs
ship weight w/o batteries: 320 lbs
dimensions (l x w x h): 53.5 in x 22 in x 38.5 in
Parts
Can't find what you need? Click here or call 1-800-USA-CLEAN
In the market for a new machine? You can find quality new and reconditioned floor care equipment at one of our vendor partners:
Need a professional? We offer service both virtually and in person.
Learn more

Diagrams
- View all diagrams
- - Frequently Replaced Parts
- - Batteries
- - Chargers
- - Commonly Asked For Parts
- - Pad Holders
- Batteries, Brushes and Charger
- Brush Drive Assembly
- Brush Lift Assembly
- Brush Skirt Assembly
- Control Console Assembly
- Pads
- Recovery Tank Assembly
- Solution Control Assembly
- Solution Tank Assembly
- Squeegee Assembly
- Wiring Diagram
Manuals
Bulletins
- Viper Fang 20/20T Tech Bulletin - Adjustable Squeegee Bracket Device
- Viper Fang 20/20T Tech Bulletin - Swivel Caster Replacing Instruction
