Fast, efficient sweeping for hard and soft floors

Flexible and Efficient on Dual-Surfaces
The Tornado SWB 26/8 Battery Sweeper moves effortlessly between carpet and hard floors. In any application were a wide-area corded vacuum isn't practical, the SWB 26/8 Walk-Behind Battery Sweeper is the perfect solution. Faster and quieter than wide-area vacuums, the SWB 26/8 is at home in schools, hospitals, airports, commercial office buildings, theaters, retail, stores, casinos, sports facilities, and arenas. With a 26" wide cleaning path and easy maneuverability, the SWB 26/8 picks up all types of debris even hard-to-pick-up items such as sand, popcorn, packaging material, tags, and clips.

What's more, you can move easily from carpeted spaces onto hard floors without changing the broom with this super-flexible unit, resulting in maximum cleaning efficiency. As an added bonus, since the Tornado SWB 26/8 is bagless and collects into a hopper, you're not spending money on bags, while also avoiding downtime.

Compact, Powerful and Battery Operated
The SWB 26/8 walk-behind sweeper is ideal for cleaning areas both large and small, running on eco-friendly, sealed 24-volt-batteries which eliminate the worry of tripping over a power cord. The SWB 26/8 offers a convenient on-board battery charger, plus whisper-quiet operation perfect for day cleaning indoors on any floor type.

Optimum Sweeping Method
The SWB 26/8 uses overthrow sweeping technology to guarantee optimum utilization of waste container capacity. The main broom has chevron bristles and is height-adjustable for professional sweeping results on all kinds of surfaces with a variety of debris. The side-mounted brush is protected by a bump guard and is raised and lowered easily by the hand controls. A high-efficiency filter and dust control system reduces dust for improved air quality.

Benefits of the Overthrow Method:
•All debris passing over the cord of the roller brushes is collected
•The flexibility of the brushes easily picks up objects large and small;
•With no front end direct collector, the debris is never pushed along in front of the sweeper.
•With no rubber lip in the way, even light, bulky objects such as dry leaves and packing material are picked up with ease;
•The side brush increases the width of your edge-cleaning path, reaching under the edge of hard floors and carpets, pulling light weight material such as paper into the dirt collector
•Top loading dirt collector can be filled up 75% of capacity, unlike front load machines

Key features:
•Ideal replacement for manual sweeping
•Moves easily from hard floors to carpeted spaces and back again
•Maximize sweeping speed up to 26,000 sq. ft. per hour-more than two-and-a-half times faster than wide-area vacuums and ten times faster than a manual broom
•Unique Overthrow System for greater cleaning efficiency
•Whisper-quiet at 67 dBA for noise sensitive environments
•Dust-control filter system for improved quality
•24 volt battery powered
•Efficient top-loading dirt collector minimizes dumping of dirt, compared to front-loading systems
•Large, non-marking rear wheels and front castor for enhanced mobility
•Collapsible handle for storage in small areas
•Compact design goes through any standard door and goes where large, ride-on sweepers cannot.

Batteries 24 V
Cleaning Path 26 in / 66 cm
Capacity 9 gal / 40 liters
Dust Control Filter
Filtration Level 3 Micron @ 99.7%
WORK RATING (ft2 per hr. / m2 per hr.) 26,000 ft2 per hr.
(2,400 m2 per hr.)
Dimensions (l x W x H)(IN./CM) 32 in x 28 in x 24 in
(80 cm x 70 cm x 60 cm)
Sound Level 67 dB (A)
Weight (with batteries) 124 lbs. / 56 kg
