Working width: 26 in (66 cm), 28 in (71.1 cm), 32 in (81.3 cm)
Brush type: dual disc (26, 28, 32), cylindrical (28), orbital (28)
Productivity theoretical max, dual disc (per hour): 28,600 sq ft (2,657 sq m) (26), 30,800 sq ft (2,861 sq m) (28), 35,200 sq ft (3,270 sq m) (32)
Productivity theoretical max, cylindrical (per hour): 30,800 sq ft (2,861 sq m)
Productivity theoretical max, orbital (per hour): 28,800 sq ft (2,601 sq m)
Estimated coverage conventional, dual disc (per hour): 20,571 sq ft (1,911 sq m) (26), 22,286 sq ft (2,070 sq m) (28), 25,714 sq ft (2,389 sq m)
Estimated coverage conventional, cylindrical (per hour): 22,286 sq ft (2,070 sq m)
Estimated coverage conventional, orbital (per hour): 20,260 sq ft (1,882 sq m)
Estimated coverage ec-h2O NanoClean, dual disc (per hour): 23,124 sq ft (2,148 sq m) (26), 23,680 sq ft (2,200 sq m) (28), 27,323 sq ft (2,538 sq m) (32)
Estimated coverage ec-h2O NanoClean, cylindrical (per hour): 23,680 sq ft (2,200 sq m)
Estimated coverage ec-h2O NanoClean, orbital (per hour): 21,527 sq ft (2,000 sq m)
System voltage: 24 V (2)
System voltage, orbital: 24 V
Scrub motor power: 0.75 hp (55 kW)
Scrub motor power, cylindrical: 0.63 hp (0.47 kW)
Brush pad speed, dual disc: 220 rpm
Brush pad speed, cylindrical: 1,500 rpm
Brush pad speed, orbital: 2,200 rpm
Brush down pressure, dual disc (low/high): 65/120lbs (29.5/54.5 kg) (26), 70/120lbs (29.5/54.5 kg) (28), 75/120lbs (29.5/54.5 kg)
Brush down pressure, cylindrical: 85/120lbs (38.5/54.5 kg)
Brush down pressure, orbital: 110/170lbs (50/77 kg)
Solution tank capacity: 22.5gal (85L)
Recovery tank capacity: 27gal (102L)
Vacuum motor power: 0.46 hp (0.34 kW)
Waterlift: 34 in (86.4 cm)
Battery run time, dual disc: 4.5h (26, 28), 4.2h (32)
Battery run time, cylindrical: 3.6h
Battery run time, orbital: 4h
Dimensions, Length x Width x Height (dual disc): 58.5 x 27.5 x 43.3 in (148.6 x 70 x 110 cm) (26), 59.1 x 29.5 x 43.3 in (150.1 x 75 x 110 cm) (28), 61.1 x 33.5 x 43.3 in (155.2 x 85 x 110 cm) (32)
Dimensions, Length x Width x Height (cylindrical): 59.1 x 30.7 x 43.3 in (150.1 x 78 x 110 cm)
Dimensions, Length x Width x Height (orbital): 58.5 x 28 x 43.3 (148.6 x 71 x 110 cm)
Weight with batteries, dual disc: 610lbs (277 kg) (26), 620lbs (281 kg) (28), 645lbs (293 kg) (32)
Weight with batteries, cylindrical & orbital: 660lbs (299 kg)
Sound level, dual disc: 67.4 dB(A)
Sound level, cylindrical: 68.3 dB(A)
Sound level, orbital: 66.9 dB(A)
Tennant T500e Parts and Support
the tennant t500e is a battery-powered, walk-behind autoscrubber. reduce the risk of mold and bacteria with easy access tanks for better cleaning. the accessible port at the front of the machine allows for quick and easy refilling of the unit, allowing you to get back to cleaning faster. simple controls and ergonomics allow operators of any skill level to maneuver the t500e with ease.
working width: 26 in (66 cm), 28 in (71.1 cm), 32 in (81.3 cm)
brush type: dual disc (26, 28, 32), cylindrical (28), orbital (28)
productivity theoretical max, dual disc (per hour): 28,600 sq ft (2,657 sq m) (26), 30,800 sq ft (2,861 sq m) (28), 35,200 sq ft (3,270 sq m) (32)
productivity theoretical max, cylindrical (per hour): 30,800 sq ft (2,861 sq m)
productivity theoretical max, orbital (per hour): 28,800 sq ft (2,601 sq m)
estimated coverage conventional, dual disc (per hour): 20,571 sq ft (1,911 sq m) (26), 22,286 sq ft (2,070 sq m) (28), 25,714 sq ft (2,389 sq m)
estimated coverage conventional, cylindrical (per hour): 22,286 sq ft (2,070 sq m)
estimated coverage conventional, orbital (per hour): 20,260 sq ft (1,882 sq m)
estimated coverage ec-h2o nanoclean, dual disc (per hour): 23,124 sq ft (2,148 sq m) (26), 23,680 sq ft (2,200 sq m) (28), 27,323 sq ft (2,538 sq m) (32)
estimated coverage ec-h2o nanoclean, cylindrical (per hour): 23,680 sq ft (2,200 sq m)
estimated coverage ec-h2o nanoclean, orbital (per hour): 21,527 sq ft (2,000 sq m)
system voltage: 24 v (2)
system voltage, orbital: 24 v
scrub motor power: 0.75 hp (55 kw)
scrub motor power, cylindrical: 0.63 hp (0.47 kw)
brush pad speed, dual disc: 220 rpm
brush pad speed, cylindrical: 1,500 rpm
brush pad speed, orbital: 2,200 rpm
brush down pressure, dual disc (low/high): 65/120lbs (29.5/54.5 kg) (26), 70/120lbs (29.5/54.5 kg) (28), 75/120lbs (29.5/54.5 kg)
brush down pressure, cylindrical: 85/120lbs (38.5/54.5 kg)
brush down pressure, orbital: 110/170lbs (50/77 kg)
solution tank capacity: 22.5gal (85l)
recovery tank capacity: 27gal (102l)
vacuum motor power: 0.46 hp (0.34 kw)
waterlift: 34 in (86.4 cm)
battery run time, dual disc: 4.5h (26, 28), 4.2h (32)
battery run time, cylindrical: 3.6h
battery run time, orbital: 4h
dimensions, length x width x height (dual disc): 58.5 x 27.5 x 43.3 in (148.6 x 70 x 110 cm) (26), 59.1 x 29.5 x 43.3 in (150.1 x 75 x 110 cm) (28), 61.1 x 33.5 x 43.3 in (155.2 x 85 x 110 cm) (32)
dimensions, length x width x height (cylindrical): 59.1 x 30.7 x 43.3 in (150.1 x 78 x 110 cm)
dimensions, length x width x height (orbital): 58.5 x 28 x 43.3 (148.6 x 71 x 110 cm)
weight with batteries, dual disc: 610lbs (277 kg) (26), 620lbs (281 kg) (28), 645lbs (293 kg) (32)
weight with batteries, cylindrical & orbital: 660lbs (299 kg)
sound level, dual disc: 67.4 db(a)
sound level, cylindrical: 68.3 db(a)
sound level, orbital: 66.9 db(a)
working width: 26 in (66 cm), 28 in (71.1 cm), 32 in (81.3 cm)
brush type: dual disc (26, 28, 32), cylindrical (28), orbital (28)
productivity theoretical max, dual disc (per hour): 28,600 sq ft (2,657 sq m) (26), 30,800 sq ft (2,861 sq m) (28), 35,200 sq ft (3,270 sq m) (32)
productivity theoretical max, cylindrical (per hour): 30,800 sq ft (2,861 sq m)
productivity theoretical max, orbital (per hour): 28,800 sq ft (2,601 sq m)
estimated coverage conventional, dual disc (per hour): 20,571 sq ft (1,911 sq m) (26), 22,286 sq ft (2,070 sq m) (28), 25,714 sq ft (2,389 sq m)
estimated coverage conventional, cylindrical (per hour): 22,286 sq ft (2,070 sq m)
estimated coverage conventional, orbital (per hour): 20,260 sq ft (1,882 sq m)
estimated coverage ec-h2o nanoclean, dual disc (per hour): 23,124 sq ft (2,148 sq m) (26), 23,680 sq ft (2,200 sq m) (28), 27,323 sq ft (2,538 sq m) (32)
estimated coverage ec-h2o nanoclean, cylindrical (per hour): 23,680 sq ft (2,200 sq m)
estimated coverage ec-h2o nanoclean, orbital (per hour): 21,527 sq ft (2,000 sq m)
system voltage: 24 v (2)
system voltage, orbital: 24 v
scrub motor power: 0.75 hp (55 kw)
scrub motor power, cylindrical: 0.63 hp (0.47 kw)
brush pad speed, dual disc: 220 rpm
brush pad speed, cylindrical: 1,500 rpm
brush pad speed, orbital: 2,200 rpm
brush down pressure, dual disc (low/high): 65/120lbs (29.5/54.5 kg) (26), 70/120lbs (29.5/54.5 kg) (28), 75/120lbs (29.5/54.5 kg)
brush down pressure, cylindrical: 85/120lbs (38.5/54.5 kg)
brush down pressure, orbital: 110/170lbs (50/77 kg)
solution tank capacity: 22.5gal (85l)
recovery tank capacity: 27gal (102l)
vacuum motor power: 0.46 hp (0.34 kw)
waterlift: 34 in (86.4 cm)
battery run time, dual disc: 4.5h (26, 28), 4.2h (32)
battery run time, cylindrical: 3.6h
battery run time, orbital: 4h
dimensions, length x width x height (dual disc): 58.5 x 27.5 x 43.3 in (148.6 x 70 x 110 cm) (26), 59.1 x 29.5 x 43.3 in (150.1 x 75 x 110 cm) (28), 61.1 x 33.5 x 43.3 in (155.2 x 85 x 110 cm) (32)
dimensions, length x width x height (cylindrical): 59.1 x 30.7 x 43.3 in (150.1 x 78 x 110 cm)
dimensions, length x width x height (orbital): 58.5 x 28 x 43.3 (148.6 x 71 x 110 cm)
weight with batteries, dual disc: 610lbs (277 kg) (26), 620lbs (281 kg) (28), 645lbs (293 kg) (32)
weight with batteries, cylindrical & orbital: 660lbs (299 kg)
sound level, dual disc: 67.4 db(a)
sound level, cylindrical: 68.3 db(a)
sound level, orbital: 66.9 db(a)
Parts
Can't find what you need? Click here or call 1-800-USA-CLEAN
In the market for a new machine? You can find quality new and reconditioned floor care equipment at one of our vendor partners:
Need a professional? We offer service both virtually and in person.
Learn more
Diagrams
- View all diagrams
- - Pad Holders
- - Pads - 16 inch
- -13 Inch Pads
- -14 Inch Pads
- -Orbital Pads
- Automatic Battery Watering Module Assembly
- Battery Assembly
- Battery Cable Assembly
- Brushes and Pads Assembly - Disk
- Burshes and Pads Assemby - Cylindrical and Orbital
- Console Assembly
- Drain Hose Assembly
- ec-H2O Nanoclean Module Assembly
- ec-H2O Solution Assembly
- Electrical Assembly
- Electrical Diagram 1
- Electrical Diagram 2
- Electrical Diagram 3
- Electrical Diagram 4
- Electrical Harness - Bail Switch
- Electrical Harness - Operator Station 1
- Electrical Harness 1
- Electrical Harness 2
- Electrical Harness 3
- Electrical Harness 4
- Electrical Harness 5
- Electrical Harness 6
- Electrical Harness- Operator Station 2
- Frame and Drive Assembly
- Hydrolink Manual Battery Watering Assembly
- Lift Out Battery Box - After SN 29999999
- New Style Squeegee Assembly-26, 28, and 32 inch
- Off-Board Charger Assembly
- Old Style Squeegee Assembly-26, 28, and 32 inch
- On-Board Charger Assembly
- Orbital Head Eccentric Drive Assembly
- Parking Brake Assembly
- Recovery Tank Assembly
- Scrub Head Assembly- Cylindrical
- Scrub Head Assembly- Disk
- Scrub Head Assembly- Orbital
- Scrub Head Housing Assembly- Cylindrical
- Scrub Head Lift Assembly - Cylindrical
- Scrub Head Lift Assembly - Disk
- Scrub Head Lift Assembly - Orbital
- Smart-Fill Automatic Battery Watering Assembly
- Solution Tank Assembly
- Squeegee Assembly - 20 inch
- Squeegee Lift Assembly
- Standard Solution Assembly
- Telemetry Battery Cable Assembly
- Telemetry Electrical Assembly
Manuals
- Tennant T500e Operators Manual
- Tennant T500E Parts Manual SN 1-2
- Tennant T500E Parts Manual SN 3 - 4
Bulletins
- Instruction- ec-H20 Nanoclean Module Controller Kit 9014127-9018614
- Instruction- ec-H2O NanoClean Replacement Kit 9011810-9018615
- Instruction- IRIS Control Board Replacement Kit 9015787
- Instruction- Maximize Squeegee Blade Life
- Instruction- Membrane Bezel Kit 9015778-9015780
- Instruction- Parking Brake Kit 9015485
- Instruction- Severe Enviroment Lockout Kit 9017884
- Instruction- Spray Nozzle Rinse Kit 9015481
- Instruction-Float Switch Shield Kit 9018447
- Instruction-Orbital Scrub Head Kit 9015315
- tsb_286tn - Membrane UI Board Behavior Issues
