Features
• It has a new touchscreen that prompts users through the simple operating process, making it very easy to use.
• Sensors provide a 360-degree view that allow the sweeper/ scrubber to operate Hands-Free. Just prep, point and go!
• Uses up to 85% less water and cleaning solution per eight-hour shift; accommodates most eco-friendly solutions.
Solution Tank: 14 gal (53 liters)
Vacuum Motor: Single 67 CFM vacuum
Battery: 180 AH, 24 VDC output
Battery Run Time: Approximately 4 hours*
Machine Weight Net: 690 lbs. (312.9 kg)
Dimensions(L x W x H): 48 x 32 x 43 in (121.92 x 81.28 x 109.22 cm)
Brush System: Two 24 VDC, 0.75 HP, 200 RPM, permanent magnet type, direct drive
Scrubbing Width: 29 in (73.66 cm)
Scrubbing Pressure: 100 lbs. (45.36 kg)
Cleaning Rate: Approximately 10,000 sq ft (approx. 929 sq m) per hour
Noise Level: 65 dBA Normal Operation Interactive Service Guide
TASKI by Diversey swingobot 1650 Parts and Support
the new taski intellibot swingobot 1650 is a scrubber for hard surfaces that improves cleaning consistency and reduces cleaning costs.
features
• it has a new touchscreen that prompts users through the simple operating process, making it very easy to use.
• sensors provide a 360-degree view that allow the sweeper/ scrubber to operate hands-free. just prep, point and go!
• uses up to 85% less water and cleaning solution per eight-hour shift; accommodates most eco-friendly solutions.
solution tank: 14 gal (53 liters)
vacuum motor: single 67 cfm vacuum
battery: 180 ah, 24 vdc output
battery run time: approximately 4 hours*
machine weight net: 690 lbs. (312.9 kg)
dimensions(l x w x h): 48 x 32 x 43 in (121.92 x 81.28 x 109.22 cm)
brush system: two 24 vdc, 0.75 hp, 200 rpm, permanent magnet type, direct drive
scrubbing width: 29 in (73.66 cm)
scrubbing pressure: 100 lbs. (45.36 kg)
cleaning rate: approximately 10,000 sq ft (approx. 929 sq m) per hour
noise level: 65 dba normal operation
features
• it has a new touchscreen that prompts users through the simple operating process, making it very easy to use.
• sensors provide a 360-degree view that allow the sweeper/ scrubber to operate hands-free. just prep, point and go!
• uses up to 85% less water and cleaning solution per eight-hour shift; accommodates most eco-friendly solutions.
solution tank: 14 gal (53 liters)
vacuum motor: single 67 cfm vacuum
battery: 180 ah, 24 vdc output
battery run time: approximately 4 hours*
machine weight net: 690 lbs. (312.9 kg)
dimensions(l x w x h): 48 x 32 x 43 in (121.92 x 81.28 x 109.22 cm)
brush system: two 24 vdc, 0.75 hp, 200 rpm, permanent magnet type, direct drive
scrubbing width: 29 in (73.66 cm)
scrubbing pressure: 100 lbs. (45.36 kg)
cleaning rate: approximately 10,000 sq ft (approx. 929 sq m) per hour
noise level: 65 dba normal operation
Parts
Can't find what you need? Click here or call 1-800-USA-CLEAN
In the market for a new machine? You can find quality new and reconditioned floor care equipment at one of our vendor partners:
Need a professional? We offer service both virtually and in person.
Learn more
Diagrams
- View all diagrams
- - Pad Holders
- Battery Boc Compartment Assembly - Drawing 3
- Battery Box Assembly
- Battery Box Compartment Assembly - Drawing 1
- Battery Box Compartment Assembly - Drawing 2
- Bristle Skirt - with Hardware Assembly
- Brush/Scrub Deck Assembly - Drawing 1
- Control Panel Assembly
- Electrical Enclosure Assembly - Drawing 1
- Electrical Enclosure Assembly - Drawing 2
- Electrical Enclosure Assembly - Drawing 3
- Front Door - Proximity Board and Hinge Pocket Assembly
- Front Door - Proximity Board Assembly
- Front Door - USB Hub Panel with Hardware Assembly
- Front Door Assembly
- Front Door Hinge with Magnetic Switch and Hardware Assembly
- Front Door with Front Touch Shield and Hardware Assembly
- Healthcare/UV Components Assembly
- Rear Cover Assembly
- Rear Filter Assembly - Drawing 2
- Rear Filter Assembly - Drawing 3
- Rear Filter Assembly - Drawing 4
- Rear Filter Assembly - Filters and (Parallel)Hose Routing
- Rear Filter Assembly - Filters and (UV/Healthcare)Hose Routing
- Rolling Chassis Assembly - Brake Drawing
- Rolling Chassis Assembly - Frame Drawing 1
- Rolling Chassis Assembly - Frame Drawing 2
- Rolling Chassis Assembly - Left Motor
- Rolling Chassis Assembly - Right Motor
- Rolling Chassis Assembly - Sheet Metal
- Side and Rear Bumpers Assembly
- Solenoid Tower Drawing 1 with Components Assembly
- Solenoid Tower Drawing 2 with Components Assembly
- Spray Guard Brush Assembly
- Squeegee Assembly
- Squeegee Mount Assembly
- Srub Head Assembly - Drawing 2
- Tank Assembly - Drawing 1
- Tank Assembly - Drawing 2
- Tank Lid Assembly
