Benefits of CS7010 Hybrid & Battery Drive Sweeper-Scrubbers. The CS7010 takes sustainable cleaning to the next level. You’ll reduce your cleaning time and costs from the benefits of dedicated dry sweeping and wet scrubbing in a single pass, and achieve up to 30% fuel savings from Hybrid technology. The CS7010’s low maintenance, leak-free Electric Drive Technology replaces inefficient, higher maintenance hydraulic systems.
-Clean more sustainably, with up to 30% savings on water and detergent, with the standard SmartFlow™, and even more with the optional EcoFlex™ system
-Choose from the broadest range of machine power configurations in the industry — Hybrid – Kubota LPG, diesel, or gasoline plus superior run-time battery and fuel cell
-Complete dry sweeping system with dual side brooms, powerful main broom, dust control system, and high capacity 7 ft 3 high-lift hopper system
-Control airborne dust generated by the side brooms with optional DustGuard™
-Improve air quality with the Donaldson PowerCore® Ultra-Web™ nanofilter with MERV 13 rating and a variable frequency shaker
-Ensure operator safety with our Clear-View™ design, automatic speed reduction in turns and seat-accessible hopper safety prop rod
-Simplify routine maintenance and minimize service costs with MaxAccess™ design
Sweeping path w./ dual side brooms (cm): 61 in (154 cm) - Squeegee path width is fully swept
Main broom: 36 in (90 cm) x 12.2 in (31 cm)
Dust control: 115 ft2 (`10.7 m2) Donalson high-capacity PowerCore® UltraWeb® filter w/synthetic media. Variable frequency automatic filter shaker
Debris hopper dump height: 60 in (152 cm)
Hopper capacity ft³ (l): 7 ft3 (198 L) 300 lb (136 kg)
DustGuard™ Tank Capacity (optional): 29 gal (110 L)
Scrub path in. (cm): 48 in (122 cm)
Brushes/pads qty.: 3 x 17 in (43 cm) disc
Max. scrubbing coverage rate per hour: 118,600 ft2 (11,000 m2)
Scrub pressure lbs (kg): Three scrub pressure settings up to 400 lb (182 kg) of down force at maximum setting
Solution/recovery tank capacity: 75 gal (285 L) each
Vacuum: Recovery - Dual vac fan motors capable of 65 in (165 cm) waterlift
Power: Kubota WG972: 3 cyl., 0.96 L - 30 hp (22.0 kW)
Propulsion system: Variable speed brushless A/C drive
Max. transport speed mph (km/h): 5.5 mph (8.9 km/h)
Max sweeping speed (KM/H): 3.5 mph (5.6 km/h) w/override capability
Max. scrub speed: 3.5 mph (5.6 km/h) w/override capability
Operational run time (hr)Sweeping/Scrubbing: 2 - LPG - 5.5 hrs. w/32 lb (14.5 kg) tank
Gradeability transport % (DEG): @gross weight—Scrubbing 21% (12 deg.); Sweeping 17.6% (10 deg.)
Length: 103 in (262 cm)
Width: 48 in (122 cm)
Height: [59 in (150 cm)] [82 in (208 cm) std. overhead guard] [79 in (201 cm) low clearance overhead guard]
Min. aisle turn (cm): 104 in (264 cm)
Gross vehicle weight lbs (kg): 4,676 lb (2,121 kg)
Empty weight: 3,636 lb (1,649 kg)
Sweeping coverage rate per hour: 146,400 sq ft (13,600 sq m)
Sound level (IEC60335-2-72): 82 dB A
Water Ingression: All electric drive motors and actuators rated IP55 for water washdown
