Machine width (without side brushes) 36.8 in (937 mm)
Machine maximum height (at the steering wheel) 50.3 in (1,250 mm)
Cleaning width (without side brushes) 27.6 in (700 mm)
Cleaning width (with side brushes) 50.8 in (1,290 mm)
Minimum distance from the floor (skirts not included) 2.6 in (67 mm)
Main brush size (diameter x length) 11.8 x 27.6 in (300 mm x 700 mm)
Side brush diameter 17.7 in (450 mm)
Main brush speed 550 rpm
Side brush speed 80 rpm
Front steering wheel diameter 11.8 in (300 mm)
Rear driving wheel diameter 11.8 in (300 mm)
Front wheel specific pressure on the floor 159.5 psi (1.1 N/mm2)
Rear wheel specific pressure on the floor 101.5 psi (0.7 N/mm2)
Total machine weight (without batteries) 573.2 lb (255 kg)
Hopper capacity 21.2 gal (80 liters)
Main brush motor 0.67 HP (500 W)
Side brush motors 0.1 HP (80 W)
Drive system motor 0.8 HP (600 W), 110 rpm
Vacuum system motor 0.41 HP (310 W)
Filter shaker motor 0.13 HP (100 W), 6,500 rpm
Sound pressure level at workstation (A Lpa) 63.8 dB(A)
Vibration level at the operator’s arms (*) <8.2ft/s2
(2.5m/s2)
Vibration level at the operator’s body (*) <1.9ft/s2
(0.6m/s2)
Maximum forward/reverse speed 3.7 mph (6 km/h)
Maximum reverse speed 1.8 mph (3 km/h)
Gradeability 11.3° (20 %)
Minimum turning radius 51.6 in(1,310mm)
Battery voltage 24 V
Battery capacity 260 Ah C20 (WET)
Battery capacity 220 Ah C20 (AGM)
Battery container inner size (length x width x height) 21x14.7x6.1in(534x374x155mm)
ICE Intelligent Cleaning Equipment IS1100 Parts and Support
machine length 59 in (1,500 mm)
machine width (without side brushes) 36.8 in (937 mm)
machine maximum height (at the steering wheel) 50.3 in (1,250 mm)
cleaning width (without side brushes) 27.6 in (700 mm)
cleaning width (with side brushes) 50.8 in (1,290 mm)
minimum distance from the floor (skirts not included) 2.6 in (67 mm)
main brush size (diameter x length) 11.8 x 27.6 in (300 mm x 700 mm)
side brush diameter 17.7 in (450 mm)
main brush speed 550 rpm
side brush speed 80 rpm
front steering wheel diameter 11.8 in (300 mm)
rear driving wheel diameter 11.8 in (300 mm)
front wheel specific pressure on the floor 159.5 psi (1.1 n/mm2)
rear wheel specific pressure on the floor 101.5 psi (0.7 n/mm2)
total machine weight (without batteries) 573.2 lb (255 kg)
hopper capacity 21.2 gal (80 liters)
main brush motor 0.67 hp (500 w)
side brush motors 0.1 hp (80 w)
drive system motor 0.8 hp (600 w), 110 rpm
vacuum system motor 0.41 hp (310 w)
filter shaker motor 0.13 hp (100 w), 6,500 rpm
sound pressure level at workstation (a lpa) 63.8 db(a)
vibration level at the operator’s arms (*) <8.2ft/s2
(2.5m/s2)
vibration level at the operator’s body (*) <1.9ft/s2
(0.6m/s2)
maximum forward/reverse speed 3.7 mph (6 km/h)
maximum reverse speed 1.8 mph (3 km/h)
gradeability 11.3° (20 %)
minimum turning radius 51.6 in(1,310mm)
battery voltage 24 v
battery capacity 260 ah c20 (wet)
battery capacity 220 ah c20 (agm)
battery container inner size (length x width x height) 21x14.7x6.1in(534x374x155mm)
machine width (without side brushes) 36.8 in (937 mm)
machine maximum height (at the steering wheel) 50.3 in (1,250 mm)
cleaning width (without side brushes) 27.6 in (700 mm)
cleaning width (with side brushes) 50.8 in (1,290 mm)
minimum distance from the floor (skirts not included) 2.6 in (67 mm)
main brush size (diameter x length) 11.8 x 27.6 in (300 mm x 700 mm)
side brush diameter 17.7 in (450 mm)
main brush speed 550 rpm
side brush speed 80 rpm
front steering wheel diameter 11.8 in (300 mm)
rear driving wheel diameter 11.8 in (300 mm)
front wheel specific pressure on the floor 159.5 psi (1.1 n/mm2)
rear wheel specific pressure on the floor 101.5 psi (0.7 n/mm2)
total machine weight (without batteries) 573.2 lb (255 kg)
hopper capacity 21.2 gal (80 liters)
main brush motor 0.67 hp (500 w)
side brush motors 0.1 hp (80 w)
drive system motor 0.8 hp (600 w), 110 rpm
vacuum system motor 0.41 hp (310 w)
filter shaker motor 0.13 hp (100 w), 6,500 rpm
sound pressure level at workstation (a lpa) 63.8 db(a)
vibration level at the operator’s arms (*) <8.2ft/s2
(2.5m/s2)
vibration level at the operator’s body (*) <1.9ft/s2
(0.6m/s2)
maximum forward/reverse speed 3.7 mph (6 km/h)
maximum reverse speed 1.8 mph (3 km/h)
gradeability 11.3° (20 %)
minimum turning radius 51.6 in(1,310mm)
battery voltage 24 v
battery capacity 260 ah c20 (wet)
battery capacity 220 ah c20 (agm)
battery container inner size (length x width x height) 21x14.7x6.1in(534x374x155mm)
