Traverse 1/3 HP (0.25 kW)
Traverse Forward Speed Variable to 200 ft./min (61 m/min)
Traverse Reverse Speed Variable to 140 ft./min. (43 m/min)
Battery Protection Low Voltage Cut-Off of Brushes and Solution
Motor Vacuum 3/4 HP(.569 kW) Acoustical High Efficient Tangential 3 stg.
Solution Tank 11 Gallons (42 liters)
Solution Level Calibrated Level Indicator
Recovery Tank 11 Gallons (42 liters)
Recovery Full Indicator Electric Shut-Off
Parabolic Squeegee Swing type with breakaway feature, No tool operation feature, 32" (81cm) hard width with 34" (86cm) flex blade width
Squeegee Operation Reverse direction on floor and 3 - position manual lever style operation
Cleaning Swath 17" (43.2 cm)
Motor, Brush (2) 3/4 HP (0,56 kW)
Brush 2 per Machine (2) 4" (10 cm)
Brush Speed 1000 RPM
Brush Pressure 70 lbs. (31.8 kg)
Drive Wheels (2) 8" x 2" (20 cm x 5 cm) Neoprene tread
Caster 3½" X 1¼" (8.9 cm x 3.2 cm)
On-Board Charger 24 V D.C., 10 Amp, 115/60 or 24 V D.C., 10 Amp, 230/50
Grade Cleaning 2%
Length 48 ¼" (122.6 cm)
Width 20" (50.8 cm)
Height 42" (106.7 cm)
Weight w/batteries (130 AH) 360 lbs. (163.3 kg)
Shipping Weight w/Batteries (130AH) 487 lbs. (221 kg)
Line of Sight -Operator Height = 5'8" 7.5 feet (2.3 m)
Warranty Machine 3 Years, Polydur tanks 8 Years, Batteries 18 Months Pro-rated
Clarke (Alto) FOCUS L17 Parts and Support
machine power supply 24 volt d.c., (2) 12v 130ah wet or (2) 12v 100ah gel deep cycle batteries
traverse 1/3 hp (0.25 kw)
traverse forward speed variable to 200 ft./min (61 m/min)
traverse reverse speed variable to 140 ft./min. (43 m/min)
battery protection low voltage cut-off of brushes and solution
motor vacuum 3/4 hp(.569 kw) acoustical high efficient tangential 3 stg.
solution tank 11 gallons (42 liters)
solution level calibrated level indicator
recovery tank 11 gallons (42 liters)
recovery full indicator electric shut-off
parabolic squeegee swing type with breakaway feature, no tool operation feature, 32" (81cm) hard width with 34" (86cm) flex blade width
squeegee operation reverse direction on floor and 3 - position manual lever style operation
cleaning swath 17" (43.2 cm)
motor, brush (2) 3/4 hp (0,56 kw)
brush 2 per machine (2) 4" (10 cm)
brush speed 1000 rpm
brush pressure 70 lbs. (31.8 kg)
drive wheels (2) 8" x 2" (20 cm x 5 cm) neoprene tread
caster 3½" x 1¼" (8.9 cm x 3.2 cm)
on-board charger 24 v d.c., 10 amp, 115/60 or 24 v d.c., 10 amp, 230/50
grade cleaning 2%
length 48 ¼" (122.6 cm)
width 20" (50.8 cm)
height 42" (106.7 cm)
weight w/batteries (130 ah) 360 lbs. (163.3 kg)
shipping weight w/batteries (130ah) 487 lbs. (221 kg)
line of sight -operator height = 5'8" 7.5 feet (2.3 m)
warranty machine 3 years, polydur tanks 8 years, batteries 18 months pro-rated
traverse 1/3 hp (0.25 kw)
traverse forward speed variable to 200 ft./min (61 m/min)
traverse reverse speed variable to 140 ft./min. (43 m/min)
battery protection low voltage cut-off of brushes and solution
motor vacuum 3/4 hp(.569 kw) acoustical high efficient tangential 3 stg.
solution tank 11 gallons (42 liters)
solution level calibrated level indicator
recovery tank 11 gallons (42 liters)
recovery full indicator electric shut-off
parabolic squeegee swing type with breakaway feature, no tool operation feature, 32" (81cm) hard width with 34" (86cm) flex blade width
squeegee operation reverse direction on floor and 3 - position manual lever style operation
cleaning swath 17" (43.2 cm)
motor, brush (2) 3/4 hp (0,56 kw)
brush 2 per machine (2) 4" (10 cm)
brush speed 1000 rpm
brush pressure 70 lbs. (31.8 kg)
drive wheels (2) 8" x 2" (20 cm x 5 cm) neoprene tread
caster 3½" x 1¼" (8.9 cm x 3.2 cm)
on-board charger 24 v d.c., 10 amp, 115/60 or 24 v d.c., 10 amp, 230/50
grade cleaning 2%
length 48 ¼" (122.6 cm)
width 20" (50.8 cm)
height 42" (106.7 cm)
weight w/batteries (130 ah) 360 lbs. (163.3 kg)
shipping weight w/batteries (130ah) 487 lbs. (221 kg)
line of sight -operator height = 5'8" 7.5 feet (2.3 m)
warranty machine 3 years, polydur tanks 8 years, batteries 18 months pro-rated
