•5 models to choose for your application
•Superior solution pick-up
•Quiet at 65 dB(A)
•Easy operation
•Environmentally friendly with efficient solution usage
Cleaning Width: 17” (43 cm)
Working Voltage: 24 Volt DC
Standard Batteries (2): 12 Volt 130 AH @ 20 hr rating (wet) or 12 Volt 114 Ah @20 hr rating (AGM)
Battery Protection System: Low voltage cut-off of brush and solution
Vacuum Motor Power: .5 hp, 2 stage tangential discharge
Solution & Recovery Tank: 14.5 gallons (55 L each tank)
Solution Flow: 0 - .63 gallons/min (0 - 2.4 Liters/min)
Brush Motor Power: .7 hp (480 W)
Brush Pressure : 45 & 90 lbs. (20 & 41 kg)
Disc, Pad & Brush Sizes: 17” (43 cm)
Brush Speed: 153 rp
Sound Level: 65.8 db(A)
On-Board Charger: Standard
L x W x H: 52 x 29 x 42” (132 x 76 x 108 cm)
Width (without squeegee): 21” (54 cm)
Squeegee Width: 29.9” (76 cm)
Agency Approval: cETLus
Warranty: Polydur® Body - 8 Years, Parts - 3 Years, Labor - 1 Year, Battery 18 months pro-rated (1st 90 days unconditional)
Clarke (Alto) FOCUS II L17 Parts and Support
conventional disc models of the focus® ii are available with either 17” or 20” disc scrub decks. the 20” models may be selected with either power traction or brush assist drive. the 17” model is available with traction drive. the brush/pad driver installation and removal is made simple with an easy on/off push button control.
•5 models to choose for your application
•superior solution pick-up
•quiet at 65 db(a)
•easy operation
•environmentally friendly with efficient solution usage
cleaning width: 17” (43 cm)
working voltage: 24 volt dc
standard batteries (2): 12 volt 130 ah @ 20 hr rating (wet) or 12 volt 114 ah @20 hr rating (agm)
battery protection system: low voltage cut-off of brush and solution
vacuum motor power: .5 hp, 2 stage tangential discharge
solution & recovery tank: 14.5 gallons (55 l each tank)
solution flow: 0 - .63 gallons/min (0 - 2.4 liters/min)
brush motor power: .7 hp (480 w)
brush pressure : 45 & 90 lbs. (20 & 41 kg)
disc, pad & brush sizes: 17” (43 cm)
brush speed: 153 rp
sound level: 65.8 db(a)
on-board charger: standard
l x w x h: 52 x 29 x 42” (132 x 76 x 108 cm)
width (without squeegee): 21” (54 cm)
squeegee width: 29.9” (76 cm)
agency approval: cetlus
warranty: polydur® body - 8 years, parts - 3 years, labor - 1 year, battery 18 months pro-rated (1st 90 days unconditional)
•5 models to choose for your application
•superior solution pick-up
•quiet at 65 db(a)
•easy operation
•environmentally friendly with efficient solution usage
cleaning width: 17” (43 cm)
working voltage: 24 volt dc
standard batteries (2): 12 volt 130 ah @ 20 hr rating (wet) or 12 volt 114 ah @20 hr rating (agm)
battery protection system: low voltage cut-off of brush and solution
vacuum motor power: .5 hp, 2 stage tangential discharge
solution & recovery tank: 14.5 gallons (55 l each tank)
solution flow: 0 - .63 gallons/min (0 - 2.4 liters/min)
brush motor power: .7 hp (480 w)
brush pressure : 45 & 90 lbs. (20 & 41 kg)
disc, pad & brush sizes: 17” (43 cm)
brush speed: 153 rp
sound level: 65.8 db(a)
on-board charger: standard
l x w x h: 52 x 29 x 42” (132 x 76 x 108 cm)
width (without squeegee): 21” (54 cm)
squeegee width: 29.9” (76 cm)
agency approval: cetlus
warranty: polydur® body - 8 years, parts - 3 years, labor - 1 year, battery 18 months pro-rated (1st 90 days unconditional)
Parts
Can't find what you need? Click here or call 1-800-USA-CLEAN
In the market for a new machine? You can find quality new and reconditioned floor care equipment at one of our vendor partners:
Need a professional? We offer service both virtually and in person.
Learn more
Diagrams
- View all diagrams
- - Commonly Asked For Parts
- - Pad Holders
- Batteries, Brushes and Charger
- Brush System
- Chassis Assembly
- Chemical Mixing Assembly
- Control Panel System
- Electrical Components Assembly
- Electrical Components Assembly With Drive
- Handle Assemblies
- Pads
- Recovery Tank Assembly
- Solution System
- Solution Tank Assembly
- Squeegee System
- Wheel Assemblies
- Wiring Diagram - Drive Model
- Wiring Diagram - Non-Drive Model
Bulletins
Repair Guides
- REPLACING THE FWD/REV SWITCH
- CLEANING AND REPLACING THE SOLUTION FILTER
- CLEANING AND REPLACING THE SOLUTION FILTER
