• The versatility to configure the machine with various pad drivers or brushes.
• Various battery pack options.
• The off-aisle wand option sprays down water and recovers the solution.
• Choose the standard model or the deluxe feature rich luxury model.
• Large tank capacities mean fewer trips to dump and fill.
• Ergonomically designed controls fit your operator comfortably.
Rugged Features - Designed to Last
Encore large automatic scrubbers provide the longest run times, greatest capacities and lowest costs per day to operate.
Design features include:
• Heavy duty Polydur™ exteriors to prevent accidental damage common in industrial applications.
• Reinforced floating scrub deck with wall rollers and gimbaled floating brushes.
• Heavy duty transaxle cleans inclines and makes for easy loading and unloading.
• Heavy duty rear casters absorb the shock from grouted or damaged floor surfaces.
• Patented Accu-Track™ breakaway squeegee prevents damage if accidentally hooked by a post or pallet.
Power Supply /Charger: 36V (6-6V batteries) 250 and 330 115V 60Hz or 230V 50 Hz
Brush Down Pressure: 150 lbs. (68 kg)
Vacuum Motor: 3-stage tangential discharge / 1 HP (.75 kW)
Brush Motor: (2) Permanent Magnet / .75 HP (.56 kW)
Traction Motor: Transaxle / .5 HP (.37 kW)
Cleaning Swath: 33 in. (84 cm)
Brush Size /Speed: (2) 17 in. (690 cm)w/ 1 in. (25 mm) overlap 200 rpm
Traverse Speed: Variable forward to 230 ft. ( 70 m) / min.
Forward / Reverse: Variable reverse to 180 ft. (55 m) / min.
Recovery / Solution Tank: 30 / 30 gal. (114 / 114 l)
Squeegee Size / Type: 43 in. (109 cm)
Drive Wheels / Casters: (2) pneumatic (4.10 / 3.50-6) with sealant (foam optional)
Dimensions L x W x H : 63 x 28 x 44 in.(160 x 71 x 112 cm)
Machine Weight w/battery: 1028 lbs. (466 kg
Shipping Weight: 1331 lbs. (603 kg
Clarke (Alto) ENCORE S33 Parts and Support
the large encore can found cleaning hospitals, schools and shopping malls as well as in industrial applications. after many years of use, both encore standard and luxury models still provide the greatest value.
• the versatility to configure the machine with various pad drivers or brushes.
• various battery pack options.
• the off-aisle wand option sprays down water and recovers the solution.
• choose the standard model or the deluxe feature rich luxury model.
• large tank capacities mean fewer trips to dump and fill.
• ergonomically designed controls fit your operator comfortably.
rugged features - designed to last
encore large automatic scrubbers provide the longest run times, greatest capacities and lowest costs per day to operate.
design features include:
• heavy duty polydur™ exteriors to prevent accidental damage common in industrial applications.
• reinforced floating scrub deck with wall rollers and gimbaled floating brushes.
• heavy duty transaxle cleans inclines and makes for easy loading and unloading.
• heavy duty rear casters absorb the shock from grouted or damaged floor surfaces.
• patented accu-track™ breakaway squeegee prevents damage if accidentally hooked by a post or pallet.
power supply /charger: 36v (6-6v batteries) 250 and 330 115v 60hz or 230v 50 hz
brush down pressure: 150 lbs. (68 kg)
vacuum motor: 3-stage tangential discharge / 1 hp (.75 kw)
brush motor: (2) permanent magnet / .75 hp (.56 kw)
traction motor: transaxle / .5 hp (.37 kw)
cleaning swath: 33 in. (84 cm)
brush size /speed: (2) 17 in. (690 cm)w/ 1 in. (25 mm) overlap 200 rpm
traverse speed: variable forward to 230 ft. ( 70 m) / min.
forward / reverse: variable reverse to 180 ft. (55 m) / min.
recovery / solution tank: 30 / 30 gal. (114 / 114 l)
squeegee size / type: 43 in. (109 cm)
drive wheels / casters: (2) pneumatic (4.10 / 3.50-6) with sealant (foam optional)
dimensions l x w x h : 63 x 28 x 44 in.(160 x 71 x 112 cm)
machine weight w/battery: 1028 lbs. (466 kg
shipping weight: 1331 lbs. (603 kg
• the versatility to configure the machine with various pad drivers or brushes.
• various battery pack options.
• the off-aisle wand option sprays down water and recovers the solution.
• choose the standard model or the deluxe feature rich luxury model.
• large tank capacities mean fewer trips to dump and fill.
• ergonomically designed controls fit your operator comfortably.
rugged features - designed to last
encore large automatic scrubbers provide the longest run times, greatest capacities and lowest costs per day to operate.
design features include:
• heavy duty polydur™ exteriors to prevent accidental damage common in industrial applications.
• reinforced floating scrub deck with wall rollers and gimbaled floating brushes.
• heavy duty transaxle cleans inclines and makes for easy loading and unloading.
• heavy duty rear casters absorb the shock from grouted or damaged floor surfaces.
• patented accu-track™ breakaway squeegee prevents damage if accidentally hooked by a post or pallet.
power supply /charger: 36v (6-6v batteries) 250 and 330 115v 60hz or 230v 50 hz
brush down pressure: 150 lbs. (68 kg)
vacuum motor: 3-stage tangential discharge / 1 hp (.75 kw)
brush motor: (2) permanent magnet / .75 hp (.56 kw)
traction motor: transaxle / .5 hp (.37 kw)
cleaning swath: 33 in. (84 cm)
brush size /speed: (2) 17 in. (690 cm)w/ 1 in. (25 mm) overlap 200 rpm
traverse speed: variable forward to 230 ft. ( 70 m) / min.
forward / reverse: variable reverse to 180 ft. (55 m) / min.
recovery / solution tank: 30 / 30 gal. (114 / 114 l)
squeegee size / type: 43 in. (109 cm)
drive wheels / casters: (2) pneumatic (4.10 / 3.50-6) with sealant (foam optional)
dimensions l x w x h : 63 x 28 x 44 in.(160 x 71 x 112 cm)
machine weight w/battery: 1028 lbs. (466 kg
shipping weight: 1331 lbs. (603 kg
Parts
Can't find what you need? Click here or call 1-800-USA-CLEAN
In the market for a new machine? You can find quality new and reconditioned floor care equipment at one of our vendor partners:
Need a professional? We offer service both virtually and in person.
Learn more
Diagrams
- View all diagrams
- - Batteries
- - Chargers
- - Pad Holders
- -Simplified Electrical System
- -Simplified Recovery System
- -Simplified Solution System
- Batteries, Brushes and Charger - 33 inch
- Brush Motor Assembly - NON-OEM
- Connection Diagram
- Control Housing Assembly
- Pads
- Rear Cover Assembly
- Scrub Deck Assembly
- Solution and Recovery Assembly
- Squeegee Assembly
- Transaxle Assembly
- Traverse System Assembly
- Wiring Diagram
Manuals
Repair Guides
- REPLACING THE FWD/REV SWITCH
- REPLACING THE VAC MOTOR
- REPLACING THE SQUEEGY BLADES
- CLEANING AND REPLACING THE SOLUTION FILTER
