» Deluxe models are equipped with dual chemical tanks, allowing instant change from one chemical to another. This provides multiple cleaning options with no draining of tanks.
» Floating, dual counter-rotating brushes agitate the cleaning solution
into both sides of the carpet nap for even, thorough cleaning and improved carpet appearance. No operator adjustment needed.
» With the interim method using the iCapsol encapsulating chemical, the carpet is dry and ready for traffic in approximately 20 minutes.
» Low dBA of 59 during interim cleaning (Voyager DUO) and 63 (Commodore DUO).
» iCapsol interim cleaning process extends the time between scheduled deep extractions.
» Dual floating vac shoes with glide strip provide consistent contact over uneven surfaces and increased solution pick-up.
Construction: Powder-coated steel chassis, Rotationally-molded
polyethylene tanks
Vacuum Motor: Two, 3 stage, 0.75 hp (560 watts)
Solution Pump: 100 psi, diaphragm style, demand pump
Brush Motor: 0.5 hp (373 watts)
Drive System: Transaxle, self-propelled
Drive Motor: 0.74 hp (552 watts) DC, variable forward and reverse
Cleaning Path: 24" (61 cm) dual counter-rotating brushes
Cleaning Rate
Interim:1.5 mph (2.4 kph)
Restorative:0.5 mph (0.8 kph)
Transport:2.4 mph (3.9 kph)
Cleaning Rate
Interim:15,840 ft2/hr (1,472 m2/hr)
Restorative: 7,200 ft2/hr (667 m2/hr)
Solution Capacity: 31 gallon (119 ltr)
Recovery Capacity: 22 gallon (83 ltr)
Chemical Tanks
Tank A:N/A
Tank B:N/A
Brush Speed: 1000 rpm
Vacuum Shoe: Dual floating 26" path (66 cm) with low friction glide
Electrical System: 36V
Batteries (Optional): Three, 12V deep cycle, 195 or 215 A/H
Battery Charger (Optional): 36V, 20A shelf
Solution Spray: Two restorative, quick change nozzles, Two interim,
quick change nozzles, optional low flow jets
Noise Level:
Interim:59 dBA
Deep:69 dBA
Flow Rate
Interim:0.24 gpm (0.91 lpm)
Restorative:1.05 gpm (3.97 lpm)
Wheels (non-marking)
Front:Two, 9" (22.9 cm) wheels
Rear:Two, 4" (10 cm)
Dimensions (L x W x H): 59" x 32" x 43" (149.9 cm x 81.3 cm x 109 cm)
Battery Exchange (Optional): Includes two battery carts, two trays, extra battery cables, set of three, 12V deep cycle, 195 or 215 A/H batteries
Battery Exchange
Construction: Welded, powder-coated steel, Two, 4" (10 cm) non-marking casters, Two, 4" (10 cm) non-marking wheels
Windsor VOYAGER DUO Parts and Support
» Change from interim to deep cleaning process at the turn of a switch—no mechanical changeover needed.
» Deluxe models are equipped with dual chemical tanks, allowing instant change from one chemical to another. This provides multiple cleaning options with no draining of tanks.
» Floating, dual counter-rotating brushes agitate the cleaning solution
into both sides of the carpet nap for even, thorough cleaning and improved carpet appearance. No operator adjustment needed.
» With the interim method using the iCapsol encapsulating chemical, the carpet is dry and ready for traffic in approximately 20 minutes.
» Low dBA of 59 during interim cleaning (Voyager DUO) and 63 (Commodore DUO).
» iCapsol interim cleaning process extends the time between scheduled deep extractions.
» Dual floating vac shoes with glide strip provide consistent contact over uneven surfaces and increased solution pick-up.
Construction: Powder-coated steel chassis, Rotationally-molded
polyethylene tanks
Vacuum Motor: Two, 3 stage, 0.75 hp (560 watts)
Solution Pump: 100 psi, diaphragm style, demand pump
Brush Motor: 0.5 hp (373 watts)
Drive System: Transaxle, self-propelled
Drive Motor: 0.74 hp (552 watts) DC, variable forward and reverse
Cleaning Path: 24" (61 cm) dual counter-rotating brushes
Cleaning Rate
Interim:1.5 mph (2.4 kph)
Restorative:0.5 mph (0.8 kph)
Transport:2.4 mph (3.9 kph)
Cleaning Rate
Interim:15,840 ft2/hr (1,472 m2/hr)
Restorative: 7,200 ft2/hr (667 m2/hr)
Solution Capacity: 31 gallon (119 ltr)
Recovery Capacity: 22 gallon (83 ltr)
Chemical Tanks
Tank A:N/A
Tank B:N/A
Brush Speed: 1000 rpm
Vacuum Shoe: Dual floating 26" path (66 cm) with low friction glide
Electrical System: 36V
Batteries (Optional): Three, 12V deep cycle, 195 or 215 A/H
Battery Charger (Optional): 36V, 20A shelf
Solution Spray: Two restorative, quick change nozzles, Two interim,
quick change nozzles, optional low flow jets
Noise Level:
Interim:59 dBA
Deep:69 dBA
Flow Rate
Interim:0.24 gpm (0.91 lpm)
Restorative:1.05 gpm (3.97 lpm)
Wheels (non-marking)
Front:Two, 9" (22.9 cm) wheels
Rear:Two, 4" (10 cm)
Dimensions (L x W x H): 59" x 32" x 43" (149.9 cm x 81.3 cm x 109 cm)
Battery Exchange (Optional): Includes two battery carts, two trays, extra battery cables, set of three, 12V deep cycle, 195 or 215 A/H batteries
Battery Exchange
Construction: Welded, powder-coated steel, Two, 4" (10 cm) non-marking casters, Two, 4" (10 cm) non-marking wheels
» Deluxe models are equipped with dual chemical tanks, allowing instant change from one chemical to another. This provides multiple cleaning options with no draining of tanks.
» Floating, dual counter-rotating brushes agitate the cleaning solution
into both sides of the carpet nap for even, thorough cleaning and improved carpet appearance. No operator adjustment needed.
» With the interim method using the iCapsol encapsulating chemical, the carpet is dry and ready for traffic in approximately 20 minutes.
» Low dBA of 59 during interim cleaning (Voyager DUO) and 63 (Commodore DUO).
» iCapsol interim cleaning process extends the time between scheduled deep extractions.
» Dual floating vac shoes with glide strip provide consistent contact over uneven surfaces and increased solution pick-up.
Construction: Powder-coated steel chassis, Rotationally-molded
polyethylene tanks
Vacuum Motor: Two, 3 stage, 0.75 hp (560 watts)
Solution Pump: 100 psi, diaphragm style, demand pump
Brush Motor: 0.5 hp (373 watts)
Drive System: Transaxle, self-propelled
Drive Motor: 0.74 hp (552 watts) DC, variable forward and reverse
Cleaning Path: 24" (61 cm) dual counter-rotating brushes
Cleaning Rate
Interim:1.5 mph (2.4 kph)
Restorative:0.5 mph (0.8 kph)
Transport:2.4 mph (3.9 kph)
Cleaning Rate
Interim:15,840 ft2/hr (1,472 m2/hr)
Restorative: 7,200 ft2/hr (667 m2/hr)
Solution Capacity: 31 gallon (119 ltr)
Recovery Capacity: 22 gallon (83 ltr)
Chemical Tanks
Tank A:N/A
Tank B:N/A
Brush Speed: 1000 rpm
Vacuum Shoe: Dual floating 26" path (66 cm) with low friction glide
Electrical System: 36V
Batteries (Optional): Three, 12V deep cycle, 195 or 215 A/H
Battery Charger (Optional): 36V, 20A shelf
Solution Spray: Two restorative, quick change nozzles, Two interim,
quick change nozzles, optional low flow jets
Noise Level:
Interim:59 dBA
Deep:69 dBA
Flow Rate
Interim:0.24 gpm (0.91 lpm)
Restorative:1.05 gpm (3.97 lpm)
Wheels (non-marking)
Front:Two, 9" (22.9 cm) wheels
Rear:Two, 4" (10 cm)
Dimensions (L x W x H): 59" x 32" x 43" (149.9 cm x 81.3 cm x 109 cm)
Battery Exchange (Optional): Includes two battery carts, two trays, extra battery cables, set of three, 12V deep cycle, 195 or 215 A/H batteries
Battery Exchange
Construction: Welded, powder-coated steel, Two, 4" (10 cm) non-marking casters, Two, 4" (10 cm) non-marking wheels
Parts
Can't find what you need? Click here or call 1-800-USA-CLEAN
Need a professional? We offer in person service.
Learn more
Diagrams
- View all diagrams
- - Extractor Fit All Parts
- - Frequently Replaced Parts
- Battery Cart Assembly - Optional
- Battery Cart Exchange Assembly - Optional
- Battery Cart Tray Assembly - Optional
- Battery Wiring Assembly
- Brush Deck Actuator Assembly
- Brush Deck Assembly
- Brush Deck Lift Assembly
- Brush Deck Motor Assembly
- Brush Deck Mounting Assembly
- Brush Deck Shroud Assembly
- Chemical Pump Assembly - Deluxe
- Chemical Tank Assembly - Deluxe
- Chemical Valve Assembly - Deluxe
- Control Handle Assembly
- Control Panel Mounting Assembly
- Decal Assembly
- Emergency Stop Assembly - Optional
- Front Cover Assembly
- Latch and Latch Linkage Assembly - Optional
- Lower Control Panel Assembly - Basic
- Lower Control Panel Assembly - Deluxe
- Lower Frame Assembly
- Recovery Tank Assembly
- Recovery Tank Handle Assembly - Basic
- Recovery Tank Handle Assembly - Deluxe
- Solenoid Valve Assembly - Basic
- Solenoid Valve Assembly - Deluxe
- Solution Pump Assembly
- Solution Tank Assembly
- Spray Jet Assembly
- Upper Control Panel Assembly - Basic
- Upper Control Panel Assembly - Deluxe
- Upper Frame Assembly
- Vacuum Motor Assembly - Basic
- Vacuum Motor Assembly - Deluxe
- Vacuum Shoe Assembly
- Vacuum Shoe Mounting Assembly
- Wheel and Drive Assembly
- Wiring - Control Panel - Basic
- Wiring - Control Panel - Deluxe
- Wiring - Main Harness - Basic
- Wiring - Main Harness - Deluxe
- Wiring Diagram - Basic
- Wiring Diagram - Deluxe
