To help you choose the most productive rider for your facility, the Saber Glide Series is available in three cleaning width choices—28"(71 cm), 32" (81 cm) and variable width 28" to 36" (71 to 91 cm).
Cleaning Path: 28" (71 cm)
Brushes: 2 x 14" (35.5 cm)
Brush Motor: 2 x .8 hp (600 watt)
Brush Speed: 300 rpm
Brush Pressure: 0–225 lbs. (0–102 kg)
Drive Motor: 1.3 hp (970 watt)
Maximum Transport Speed: 4 mph (6.5 km/h)
Tires: 12" (30 cm) solid (standard)
Solution Control: Gravity feed, fully variable with automatic shut-off in neutral
Solution Tank: 30 gal. (114 liter)
Recovery Tank: 30 gal. (114 liter)
Vac Motor: .75 hp (552 watts), 3 stage
Electrical System: 36 V – Six 6V 250, 305 or 335 A/H batteries, Chargers available
Weight: (without batteries) 790 lbs. (369 kg)
Dimensions: (LxWxH) 64" x 33" x 54"(163 cm x 84 cm x137 cm)
Windsor SABERGLIDE 28 Parts and Support
we listened when you told us how to build the rider scrubber you need. the saber glide series was created to make the people who work with the machine more productive. from the person cleaning floors every day to the person responsible for maintenance, these riders deliver the performance features need to get the job done faster.
to help you choose the most productive rider for your facility, the saber glide series is available in three cleaning width choices—28"(71 cm), 32" (81 cm) and variable width 28" to 36" (71 to 91 cm).
cleaning path: 28" (71 cm)
brushes: 2 x 14" (35.5 cm)
brush motor: 2 x .8 hp (600 watt)
brush speed: 300 rpm
brush pressure: 0–225 lbs. (0–102 kg)
drive motor: 1.3 hp (970 watt)
maximum transport speed: 4 mph (6.5 km/h)
tires: 12" (30 cm) solid (standard)
solution control: gravity feed, fully variable with automatic shut-off in neutral
solution tank: 30 gal. (114 liter)
recovery tank: 30 gal. (114 liter)
vac motor: .75 hp (552 watts), 3 stage
electrical system: 36 v – six 6v 250, 305 or 335 a/h batteries, chargers available
weight: (without batteries) 790 lbs. (369 kg)
dimensions: (lxwxh) 64" x 33" x 54"(163 cm x 84 cm x137 cm)
to help you choose the most productive rider for your facility, the saber glide series is available in three cleaning width choices—28"(71 cm), 32" (81 cm) and variable width 28" to 36" (71 to 91 cm).
cleaning path: 28" (71 cm)
brushes: 2 x 14" (35.5 cm)
brush motor: 2 x .8 hp (600 watt)
brush speed: 300 rpm
brush pressure: 0–225 lbs. (0–102 kg)
drive motor: 1.3 hp (970 watt)
maximum transport speed: 4 mph (6.5 km/h)
tires: 12" (30 cm) solid (standard)
solution control: gravity feed, fully variable with automatic shut-off in neutral
solution tank: 30 gal. (114 liter)
recovery tank: 30 gal. (114 liter)
vac motor: .75 hp (552 watts), 3 stage
electrical system: 36 v – six 6v 250, 305 or 335 a/h batteries, chargers available
weight: (without batteries) 790 lbs. (369 kg)
dimensions: (lxwxh) 64" x 33" x 54"(163 cm x 84 cm x137 cm)
