»Floating, dual counter-rotating brushes agitate and permeate the cleaning solution into both sides of the carpet nap for even, thorough cleaning and improved carpet appearance. No operator adjustment needed.
»With the interim method using the iCapsol encapsulating chemical, the carpet is dry and ready for traffic in approximately 20 minutes.
»iCapsol interim cleaning process extends the time between scheduled deep extractions.
»Floating vac show with glide strip provide consistent contact over uneven surfaces and increases solution pick-up
»Adjustable handle flips over to operate in walk-behind mode
»On-board, 8.5 accessory tool
Construction: Steel chassis, Rotationally-molded polyethylene tanks
Vacuum Motor: 3 stage, bypass, 1.5 hp (1,119 watts), 100 cfm (2.8 m³/min), 120" (3050 mm) waterlift
Solution Pump: 100 psi (7 bar)—Restorative, 50 psi (3.5 bar)—Interim
Brush Motor: 1/2 hp (604 watts) AC with circuit breaker protection
Brushes: Two, 16" (40.6 cm), ABS core, Perform Alert™ bristle spiral pattern
Cleaning Path: 16" (40.6 cm)
Noise Level: 73 dBA
Cleaning Rate
Interim:10,560 ft2/hr @ 1.5 mph (981 m2/hr @ 2.4 kph)
Restorative:3,850 ft2/hr @ 0.5 mph (358 m2/hr @ 0.8 kph)
Flow Rate
Interim:0.09 gpm (0.34 lpm)
Restorative:1.0 gpm (3.8 lpm)
Solution Spray: One quick-disconnect jet—Restorative
One quick-disconnect jet—Interim
Solution Tank: 10 gallon (37.8 ltr)
Recovery Tank: 10 gallon (37.8 ltr)
Vacuum Shoe: 18" (45.8 cm) wide, cast aluminum
Wheels: 10" (25.4 cm), non-marking rubber
Power Cable: 50' (15 m) detachable
Dimensions (L x W x H): 30.25" x 21.5" x 49" (76.8 cm x 54.6 cm x 12.45 cm)
Weight: 166 lbs (75.3 kg) with cord
Windsor Clipper DUO (Gray) Parts and Support
»Change from interim to deep cleaning process at the turn of a switch- no mechanical changeover needed.
»Floating, dual counter-rotating brushes agitate and permeate the cleaning solution into both sides of the carpet nap for even, thorough cleaning and improved carpet appearance. No operator adjustment needed.
»With the interim method using the iCapsol encapsulating chemical, the carpet is dry and ready for traffic in approximately 20 minutes.
»iCapsol interim cleaning process extends the time between scheduled deep extractions.
»Floating vac show with glide strip provide consistent contact over uneven surfaces and increases solution pick-up
»Adjustable handle flips over to operate in walk-behind mode
»On-board, 8.5 accessory tool
Construction: Steel chassis, Rotationally-molded polyethylene tanks
Vacuum Motor: 3 stage, bypass, 1.5 hp (1,119 watts), 100 cfm (2.8 m³/min), 120" (3050 mm) waterlift
Solution Pump: 100 psi (7 bar)—Restorative, 50 psi (3.5 bar)—Interim
Brush Motor: 1/2 hp (604 watts) AC with circuit breaker protection
Brushes: Two, 16" (40.6 cm), ABS core, Perform Alert™ bristle spiral pattern
Cleaning Path: 16" (40.6 cm)
Noise Level: 73 dBA
Cleaning Rate
Interim:10,560 ft2/hr @ 1.5 mph (981 m2/hr @ 2.4 kph)
Restorative:3,850 ft2/hr @ 0.5 mph (358 m2/hr @ 0.8 kph)
Flow Rate
Interim:0.09 gpm (0.34 lpm)
Restorative:1.0 gpm (3.8 lpm)
Solution Spray: One quick-disconnect jet—Restorative
One quick-disconnect jet—Interim
Solution Tank: 10 gallon (37.8 ltr)
Recovery Tank: 10 gallon (37.8 ltr)
Vacuum Shoe: 18" (45.8 cm) wide, cast aluminum
Wheels: 10" (25.4 cm), non-marking rubber
Power Cable: 50' (15 m) detachable
Dimensions (L x W x H): 30.25" x 21.5" x 49" (76.8 cm x 54.6 cm x 12.45 cm)
Weight: 166 lbs (75.3 kg) with cord
»Floating, dual counter-rotating brushes agitate and permeate the cleaning solution into both sides of the carpet nap for even, thorough cleaning and improved carpet appearance. No operator adjustment needed.
»With the interim method using the iCapsol encapsulating chemical, the carpet is dry and ready for traffic in approximately 20 minutes.
»iCapsol interim cleaning process extends the time between scheduled deep extractions.
»Floating vac show with glide strip provide consistent contact over uneven surfaces and increases solution pick-up
»Adjustable handle flips over to operate in walk-behind mode
»On-board, 8.5 accessory tool
Construction: Steel chassis, Rotationally-molded polyethylene tanks
Vacuum Motor: 3 stage, bypass, 1.5 hp (1,119 watts), 100 cfm (2.8 m³/min), 120" (3050 mm) waterlift
Solution Pump: 100 psi (7 bar)—Restorative, 50 psi (3.5 bar)—Interim
Brush Motor: 1/2 hp (604 watts) AC with circuit breaker protection
Brushes: Two, 16" (40.6 cm), ABS core, Perform Alert™ bristle spiral pattern
Cleaning Path: 16" (40.6 cm)
Noise Level: 73 dBA
Cleaning Rate
Interim:10,560 ft2/hr @ 1.5 mph (981 m2/hr @ 2.4 kph)
Restorative:3,850 ft2/hr @ 0.5 mph (358 m2/hr @ 0.8 kph)
Flow Rate
Interim:0.09 gpm (0.34 lpm)
Restorative:1.0 gpm (3.8 lpm)
Solution Spray: One quick-disconnect jet—Restorative
One quick-disconnect jet—Interim
Solution Tank: 10 gallon (37.8 ltr)
Recovery Tank: 10 gallon (37.8 ltr)
Vacuum Shoe: 18" (45.8 cm) wide, cast aluminum
Wheels: 10" (25.4 cm), non-marking rubber
Power Cable: 50' (15 m) detachable
Dimensions (L x W x H): 30.25" x 21.5" x 49" (76.8 cm x 54.6 cm x 12.45 cm)
Weight: 166 lbs (75.3 kg) with cord
Parts
Can't find what you need? Click here or call 1-800-USA-CLEAN
Need a professional? We offer in person service.
Learn more
Diagrams
- View all diagrams
- - Commonly Asked For Parts
- Brush Deck Assembly
- Brush Deck Motor Assembly
- Brush Deck Mounting Assembly
- Control Panel Assembly
- Decals
- Hand Tool Assembly
- Handle Assembly
- Handle Bracket Assembly
- Handle Mounting Assembly
- Handle Release Lever Assembly
- Recovery Tank Assembly
- Solution Assembly-External
- Solution Assembly-Internal
- Solution Tank Assembly
- Vacuum Assembly
- Vacuum Shoe Assembly
- Vacuum Shoe Mounting Assembly
- Wheel and Axle Assembly
- Wiring Diagram Assembly
