LYNX 26

1

• Parts
• Diagrams
• Manuals

The SSS Lynx 26 Large Area Vacuum is a versatile large area vacuum cleaner that deep cleans large carpeted areas with wase. The wide cleaning path quickly cleans opens such as large meeting rooms, hallways, ballrooms, lobbies and terminals. The single 2-stage, 1.57 hp industrial motor creates a deep cleaning action across the full cleaning path. The dive height adjustments make it easy to adjust to different types of carpeting. The Lynx 26 has an optional tool kits which provides the ability to clean from floor to ceiling with one machine. For large area vacuuming the SSS Lynx 26 is your best choice.

Cleaning Path 26”
Vacuum Motor 2-stage, 1.57 HP motor
Brush Motor .33 HP
Brush Speed 1300 rpm
Productivity 11,000 sq. ft./hr (maximum productivity)
Air Flow 101 cfm
Hopper Capacity 2.65 gallon (bag capacity)
Filter Bag #86051, 10 filter bags/case
Cloth Bag optional (VA51067)
Standard Filtration 40 micron
Power Controls Single switch
Power Cord (not removable) 55 ft., 14/3 SJT (safety orange)
Cleaning Heights Manual 5-position height adjustments
Optional Accessory Kit Dusting brush, crevice tool, 9’ hose & 52” wand
Wheels 5-inch rear wheels
Body Construction Rotational molded polyethylene upper /
Engineered ABS lower
Sound Level 76.2 dBA
Belt 4.5" round polyurethane
Dimensions 18" L x 26" W x 45" H
Weight 45 lbs net; 76 lbs shipping (including cord)
