ACE 26BA

1

• Parts
• Diagrams

The SSS ACE 26BA & 26T AutoScrubbers are uniquely positioned with a smaller body, but with the scrub deck and squeegee of a 26” machine. The ACE 26BA & 26T AutoScrubbers are rugged enough to handle larger jobs, but have the affordability of a smaller machine. With an adjustable console, the ACE 26BA & 26T AutoScrubbers features simple controls and easy to read gauges to provide operators with a high comfort level. The ACE 26BA & 26T AutoScrubbers feature a 26” inch cleaning path, 13 gallon solution tank, 14 gallon recovery tank and a 34.5” inch squeegee. The durable polyethylene tanks on the scrubber are impact resistant and warranted for 10 years.

Cleaning Path: 26”
Squeegee Width: 34.5”
Productivity Rate: 22,500 sq. ft./hr.
Pad Drive Diameter: Dual 13” pad drivers
Pad Drive Speed: 220 rpm
Pad Pressure: 80 lbs.
Pad Drive Motor: 1 hp
Propulsion System: 26BA - Brush Assisted 26T - Transaxle (2 speed)
Vacuum Motor: .75 hp
Solution Tank: 13 gallons
Recovery Tank: 14 gallons
Power System: 24V battery
Charging System: 24V/15 amp
Batteries(included): 26BA - 145 AH Lead Acid (2) 26T - Maint. Free Gel 155 AH
Maximum Run: 3 hours
Sound Level: 70 dBa
Dimensions: 53” L x 40” H x 27.5” W
Weight: 26BA - 279 lbs. w/o batteries
26T - 289 lbs. w/o batteries
