FLOORKEEPER EZ24

• Parts
• Diagrams
• Docs

Value, performance, and one of the industry's most popular walk-behind scrubbers

Quiet Operation
Each of the units in the EZ Floorkeeper Series of automatic scrubbers is perfect for a wide range of flooring services from tile, linoleum and rubberized surfaces to marble and concrete. Ruggedly constructed of rotationally-molded plastic, these machines are a fundamental component in a hard-floor maintenance program. In a single pass, an EZ Floorkeeper lays solution, scrubs, and recovers dirty water, leaving a clean, dry floor behind. Tornado EZs are in use worldwide in retail store chains, grocery stores, and discount stores. Thanks to their quiet operation, compact size, and front mounted warning light, they can be used in retail settings while customers are shopping.

Versatility
Tornado’s® EZ Floorkeeper®’s provide easy operation, versatility,
innovative features and durable design for use in many different
environments including:
• Hospitals and Healthcare Facilities
• Schools and Universities
• Hotels and Resorts
• Industrial Facilities

Rugged Construction
EZ Floorkeepers are available in a 20" brush-assisted model, a 20" traction drive unit, and a 24" traction drive unit. All units feature 200 rpm brush speed, 3-stage vac motor, speed control, 13 gallon solution and recovery tank. All model s come standard with swing squeegee, pad holder, batteries, and charger.

Key Features
•Convenient recovery tank drain hose located above the brush deck
•13 gallon solution tank is easily filled through a side filler door
•See-through lid on the recovery tank allows the operator to monitor recovery tank level
•The 20” EZ-TD and the 24” EZ-TD feature a traction drive system
•Battery well is easily accessible for maintenance and service
•The EZ Floorkeeper®’s come standard with pad holder, batteries and charger

CLEANING PATH 24"
SWING SQUEEGEE 32"
BRUSH/PAD SIZE 24"
BRUSH/PAD SPEED 200 rpm
BRUSH/PAD PRESSURE 72 LBS
3-STAGE VAC MOTOR .75 HP
CFM 65
WATERLIFT 71" 7
BRUSH MOTOR 1.0 HP
DRIVE Traction Drive
FORWARD SPEED 0 to 200 fpm
REVERSE SPEED 150 fpm
SOLUTION TANK 13 GAL
RECOVERY TANK 13 GAL
DIMENSIONS (L X W X H) 53" X 28" X 37"
WEIGHT W/OUT BATTERIES 172 LBS
