Power, automatic scrubbing in a compact package

Ready for Any Floor Surface
The BR 16/3 puts the power of automatic scrubbing in a compact package ready for virtually any hard floor surface. This corded electric unit, operates in forward and reverse with a 16" scrubbing path at 660 RPMs. Cleaning approximately 3,200 square feet per hour, your small and congested spaces are clean, healthy and ready for use in no time.

The BR 16/3 comes standard with brushes, allowing you to replace your standard floor cleaning methods out of the box. Tornado also offers a wide selection of other brushes and pads. This allows the BR 16/3 to clean multiple hard floor types including:
•ceramic tile
•quarry tile
•paver brick
•raised rubber disc floors
•other challenging surfaces

Sustainability with Cylindrical Brush
Tornado's BR 16/3 cylindrical brush machine is designed for environmental sustainability. The use of cylindrical brushes conserves natural resources including water, solution and source materials. Cylindrical brush technology delivers low moisture deep scrubbing through concentrated brush speeds of 660 RPMs- almost 10 times higher than the speed of comparable rotary brush automatic scrubbers, digging deeper into uneven flooring surfaces to remove dirt that a disc unit can't reach. Cylindrical brushes also provide 4-6 times more contact pressure than rotary brush scrubbing, handling any flat or structures floor surface with ease.

Key Features
•Removable two-chamber tank system
•Adjustable brush pressure
•Cylindrical brushes spin at 660 RPMs
•Large, removable transport wheels
•Both the solution and recovery tank are removable for quick and easy disposal of solution.
•With a simple change of the brushes you can strip hard floors easily

Versatility
The BR 16/3 can be used on any hard floor surface, penetrating hard-to-clean floors due to increases contract pressure. Doing an excellent job on vinyl tile, the unit also excels on rubber, ceramic, paver brick, and other architectural or porous flooring surfaces that standard floor machines struggle to clean. Simply add the appropriate brush or pad to clean any hard surface, or add an optional carpet brush or squeegee to clean carpeted floors!

DIMENSIONS (L x W x H) 21 in x 19 in x 15 in (520 mm x 470 mm x 380 mm)
NET WEIGHT 67 lbs. / 33 kg.
SOLUTION TANK 3 gal / 10 l
RECOVERY TANK 3 gal / 10 l
PRODUCTIVITY 3200 f² per hour 300 m² per hour
BRUSH TYPE Cylindrical
BRUSH WIDTH 16 in / 400 mm
BRUSH RPM 660 RPM
CLEANING PATH 16 in / 400 mm
SOUND LEVEL 71 dB (A)
BRUSH MOTOR 1.5 HP / 1100 W / 14 A
VACUUM MOTOR 0.67 HP / 500 W / 4 A
