Pad/brush types: disk, cylindrical
Working width, disk: 26 in (66 cm), 30 in (76 cm), 34 in (86.4 cm)
Working width, cylindrical: 24 in (61 cm), 27 in (68.6 cm), 30 in (76.2 cm), 34 in (86.4 cm)
Pad sizes, disk: 13 in (33 cm) (2) (26 in), 15 in (38.1 cm) (2) (30 in), 17 in (43.2 cm) (2) (34 in)
Brush sizes, cylindrical: 22 x 5.5 in (55.9 x 14 cm) (2) (24 in), 25 x 5.5 in (63.5 x 14 cm) (2) (27 in), 28 x 5.5 in (71.1 x 14 cm) (2) (30 in), 32 x 5.5 in (81.3 x 14 cm) (2) (34 in)
Dimensions, Length x Width x Height: 56 x 24 x 43 in (142.2 x 61 x 109.2 cm)
Width, squeegee: 35 in (88.9 cm), 38 in (96.5 cm), 45 in (114.3 cm)
Weight, without batteries: 498lbs (225.9 kg) (disk), 494lbs (224.1 kg) (cylindrical)
Weight, with batteries: 875lbs (397 kg) (disk), 886lbs (402 kg) (cylindrical)
Brush/pad motor power: 0.75 hp (0.56 kW) (2)
Brush/pad speed: 200 rpm (disk), 750 rpm (cylindrical)
Brush/pad pressure: 250lbs (113.4 kg)
Battery run time: 5h
Battery rating: 210 AH
Solution tank capacity: 30gal (113.6L)
Recovery tank capacity: 30gal (113.6L)
Solution flow rate: 0-0.75gpm (2.8Lpm)
Vacuum motor power: 0.8 hp (0.6 kW)
Vacuum motor stages: 3-stage
Sound level: 71 dB(A)
Drive motor power: 0.75 hp (0.56 kW)
Forward speed: 4 mph (6.4 km/h)
Reverse speed: 2 mph (3.2 km/h)
Cleaning rate per hour, disk: 26,000 sq ft (2,415 sq m) (26 in), 30,000 sq ft (2,787 sq m) (30 in), 34,000 sq ft (3,159 sq m) (34 in)
Cleaning rate per hour, cylindrical: 24,000 sq ft (2,230 sq m) (24 in), 27,000 sq ft (2,508 sq m) (27 in), 30,000 sq ft (2,787 sq m) (30 in), 34,000 sq ft (3,159) (34 in)
Tomcat (Factory Cat) MAGNUM Parts and Support
The Tomcat Magnum is a battery-powered, walk-behind autoscrubber. The Magnum is built with steel construction, 100% stainless fasteners, and polyurethane rollers, providing excellent protection. Climbing steep ramps is a breeze thanks to the sealed, all-gear transaxle and transport speed of 4 mph. Built-in technology automatically shuts down "nonvital" systems when the battery gets too low, allowing you to continue driving it till it can be recharged.
Pad/brush types: disk, cylindrical
Working width, disk: 26 in (66 cm), 30 in (76 cm), 34 in (86.4 cm)
Working width, cylindrical: 24 in (61 cm), 27 in (68.6 cm), 30 in (76.2 cm), 34 in (86.4 cm)
Pad sizes, disk: 13 in (33 cm) (2) (26 in), 15 in (38.1 cm) (2) (30 in), 17 in (43.2 cm) (2) (34 in)
Brush sizes, cylindrical: 22 x 5.5 in (55.9 x 14 cm) (2) (24 in), 25 x 5.5 in (63.5 x 14 cm) (2) (27 in), 28 x 5.5 in (71.1 x 14 cm) (2) (30 in), 32 x 5.5 in (81.3 x 14 cm) (2) (34 in)
Dimensions, Length x Width x Height: 56 x 24 x 43 in (142.2 x 61 x 109.2 cm)
Width, squeegee: 35 in (88.9 cm), 38 in (96.5 cm), 45 in (114.3 cm)
Weight, without batteries: 498lbs (225.9 kg) (disk), 494lbs (224.1 kg) (cylindrical)
Weight, with batteries: 875lbs (397 kg) (disk), 886lbs (402 kg) (cylindrical)
Brush/pad motor power: 0.75 hp (0.56 kW) (2)
Brush/pad speed: 200 rpm (disk), 750 rpm (cylindrical)
Brush/pad pressure: 250lbs (113.4 kg)
Battery run time: 5h
Battery rating: 210 AH
Solution tank capacity: 30gal (113.6L)
Recovery tank capacity: 30gal (113.6L)
Solution flow rate: 0-0.75gpm (2.8Lpm)
Vacuum motor power: 0.8 hp (0.6 kW)
Vacuum motor stages: 3-stage
Sound level: 71 dB(A)
Drive motor power: 0.75 hp (0.56 kW)
Forward speed: 4 mph (6.4 km/h)
Reverse speed: 2 mph (3.2 km/h)
Cleaning rate per hour, disk: 26,000 sq ft (2,415 sq m) (26 in), 30,000 sq ft (2,787 sq m) (30 in), 34,000 sq ft (3,159 sq m) (34 in)
Cleaning rate per hour, cylindrical: 24,000 sq ft (2,230 sq m) (24 in), 27,000 sq ft (2,508 sq m) (27 in), 30,000 sq ft (2,787 sq m) (30 in), 34,000 sq ft (3,159) (34 in)
Pad/brush types: disk, cylindrical
Working width, disk: 26 in (66 cm), 30 in (76 cm), 34 in (86.4 cm)
Working width, cylindrical: 24 in (61 cm), 27 in (68.6 cm), 30 in (76.2 cm), 34 in (86.4 cm)
Pad sizes, disk: 13 in (33 cm) (2) (26 in), 15 in (38.1 cm) (2) (30 in), 17 in (43.2 cm) (2) (34 in)
Brush sizes, cylindrical: 22 x 5.5 in (55.9 x 14 cm) (2) (24 in), 25 x 5.5 in (63.5 x 14 cm) (2) (27 in), 28 x 5.5 in (71.1 x 14 cm) (2) (30 in), 32 x 5.5 in (81.3 x 14 cm) (2) (34 in)
Dimensions, Length x Width x Height: 56 x 24 x 43 in (142.2 x 61 x 109.2 cm)
Width, squeegee: 35 in (88.9 cm), 38 in (96.5 cm), 45 in (114.3 cm)
Weight, without batteries: 498lbs (225.9 kg) (disk), 494lbs (224.1 kg) (cylindrical)
Weight, with batteries: 875lbs (397 kg) (disk), 886lbs (402 kg) (cylindrical)
Brush/pad motor power: 0.75 hp (0.56 kW) (2)
Brush/pad speed: 200 rpm (disk), 750 rpm (cylindrical)
Brush/pad pressure: 250lbs (113.4 kg)
Battery run time: 5h
Battery rating: 210 AH
Solution tank capacity: 30gal (113.6L)
Recovery tank capacity: 30gal (113.6L)
Solution flow rate: 0-0.75gpm (2.8Lpm)
Vacuum motor power: 0.8 hp (0.6 kW)
Vacuum motor stages: 3-stage
Sound level: 71 dB(A)
Drive motor power: 0.75 hp (0.56 kW)
Forward speed: 4 mph (6.4 km/h)
Reverse speed: 2 mph (3.2 km/h)
Cleaning rate per hour, disk: 26,000 sq ft (2,415 sq m) (26 in), 30,000 sq ft (2,787 sq m) (30 in), 34,000 sq ft (3,159 sq m) (34 in)
Cleaning rate per hour, cylindrical: 24,000 sq ft (2,230 sq m) (24 in), 27,000 sq ft (2,508 sq m) (27 in), 30,000 sq ft (2,787 sq m) (30 in), 34,000 sq ft (3,159) (34 in)
