Portable low and adjustable pressure canister carpet extractors make quick work in tight areas.

Control your clean
Pick the model that meets your cleaning needs. Prevent over-wetting with an adjustable water pressure unit with built-in heater to increase cleaning power or choose the standard 100 psi model.

Simple maintenance, easy mobility
Get quick, easy access to working parts with the convenient clamshell design. The extractor’s large rear wheels increase mobility and allow for easier transportation on stairs.

Low cost life-cycle
Strong and robust construction means years of dependable use. The unique bladder design maximizes solution/recovery while minimizing the unit’s footprint.

• Straightforward, simple design makes this unit easy-to-use and maneuver
• Patented bladder design keeps machine compact
• Choose from a low pressure (100 psi) unit or adjustable pressure (0-250 psi) with heat extractor

Solution System
Solution pump pressure 0-250 psi / 0-17.22 bar (variable)
Solution pump voltage 120 V
Solution pump amps 5 A
Solution pump open flow rate 2.4 gpm / 9 L/min
Heat Exchanger
Description Cast aluminum, hairpin element cast into aluminum, surface mount thermostat; preset to 170°F (76.6°C) for safety
Vacuum System
Airflow at 2 in / 50 mm orifice 101 ft3 / 2.8 m3/h
Water lift at sealed orifice 137 in / 3480 mm (LP) / 134 in /3403 mm (HPH)
Vacuum motor type Single speed, tangential discharge, 5.7 in / 145 mm diameter, dual ball bearings,
epoxy painted fan case; recognized by UL
Vacuum motor power 1.66 hp / 1.23 kW (LP) / 2.5 hp / 1.87 kW (HPH)
Vacuum motor stages 3 stage
Vacuum motor voltage 120 V AC
Vacuum motor amps 13 A (LP) / 10 A (HPH)
Tank Capacity
Solution tank capacity 15 gal / 56.7 L
Recovery tank capacity 19 gal / 71.9 L
Chassis/Body Construction
Construction type Rotationally-molded polyethylene
Caster diameter (locking) 4 in / 100 mm
Wheel diameter 12 in / 305 mm
Power Cord
Power cord length 25 ft / 7.6 m, 1 cord / 2 cord (EX-CAN-15 HPH)
Power cord type 14 gauge 3 wire SJTO, recognized by UL and CSA, safety yellow, detachable
Dimensions/Weight/Sound Level
Length/Width/Height/Weight/Sound L:38 in / 965 mm, W: 19 in / 482 mm, H:38 in / 965 mm, Wt:110 lb / 49.8 kg (LP) 145 lb / 65.7 kg (HPH),
82 dBA
