Stop the mopping and experience the powerful cleaning abilities of the entry-level CS5 micro-scrubber. The small size and portable design make it as convenient as a mop and bucket, but it cleans and dries faster and avoids the use of dirty water for a more effective result.
-Adjustable handle adjusts to the comfort level of the operator and allows for cleaning under and around obstacles.
-Easily removable tanks allows for filling and dumping of water or solution nearly anywhere including small sinks.
-Scrubbing action standard brush with wear indicator provides a powerful clean on multi-floor surfaces and indicator shows when it’s time to replace.
-Battery charge indicator alerts operator of remaining battery power indicated by green, yellow and red lights
-Quiet running allows for cleaning in congested areas at any time of day with minimal disruption.
-Simplicity in design easy to use and operate while enabling site locations and operators to self-support and maintain.
Cleaning path 11 in / 280 mm
Productivity (per hour) Theoretical Max 10,505 ft2 / 976 m2
Estimated coverage 6,875 ft2 / 639 m2
Max speed 2.17 mph / 3.5 kmh
Brush RPM 160
Brush/pad pressure 26 lbs / 12 kg
Solution tank capacity 1.3 gal / 5 L
Recovery tank capacity 1.3 gal / 5 L
Battery run time (up to hours)* 50 mins (standard) | 75 mins (optional)
Battery voltage 36
Length x width x height (handle in upright position) 24.21 x 16.24 x 41.29 in / 615 x 412.5 x 1049 mm
Length x width x height (storage position with handle folded down) 30.31 x 16.24 x 15.7 in / 770 x 412.5 x 399 mm
Weight (with Batteries) 43.65 lbs (standard) - 44.53 lbs (optional) / 19.8 kg (standard) - 20.2 kg (optional)
Sound level (operator’s ear)** 63 dBA
Tennant CS5 Parts and Support
powerful levels of clean
stop the mopping and experience the powerful cleaning abilities of the entry-level cs5 micro-scrubber. the small size and portable design make it as convenient as a mop and bucket, but it cleans and dries faster and avoids the use of dirty water for a more effective result.
-adjustable handle adjusts to the comfort level of the operator and allows for cleaning under and around obstacles.
-easily removable tanks allows for filling and dumping of water or solution nearly anywhere including small sinks.
-scrubbing action standard brush with wear indicator provides a powerful clean on multi-floor surfaces and indicator shows when it’s time to replace.
-battery charge indicator alerts operator of remaining battery power indicated by green, yellow and red lights
-quiet running allows for cleaning in congested areas at any time of day with minimal disruption.
-simplicity in design easy to use and operate while enabling site locations and operators to self-support and maintain.
cleaning path 11 in / 280 mm
productivity (per hour) theoretical max 10,505 ft2 / 976 m2
estimated coverage 6,875 ft2 / 639 m2
max speed 2.17 mph / 3.5 kmh
brush rpm 160
brush/pad pressure 26 lbs / 12 kg
solution tank capacity 1.3 gal / 5 l
recovery tank capacity 1.3 gal / 5 l
battery run time (up to hours)* 50 mins (standard) | 75 mins (optional)
battery voltage 36
length x width x height (handle in upright position) 24.21 x 16.24 x 41.29 in / 615 x 412.5 x 1049 mm
length x width x height (storage position with handle folded down) 30.31 x 16.24 x 15.7 in / 770 x 412.5 x 399 mm
weight (with batteries) 43.65 lbs (standard) - 44.53 lbs (optional) / 19.8 kg (standard) - 20.2 kg (optional)
sound level (operator’s ear)** 63 dba
stop the mopping and experience the powerful cleaning abilities of the entry-level cs5 micro-scrubber. the small size and portable design make it as convenient as a mop and bucket, but it cleans and dries faster and avoids the use of dirty water for a more effective result.
-adjustable handle adjusts to the comfort level of the operator and allows for cleaning under and around obstacles.
-easily removable tanks allows for filling and dumping of water or solution nearly anywhere including small sinks.
-scrubbing action standard brush with wear indicator provides a powerful clean on multi-floor surfaces and indicator shows when it’s time to replace.
-battery charge indicator alerts operator of remaining battery power indicated by green, yellow and red lights
-quiet running allows for cleaning in congested areas at any time of day with minimal disruption.
-simplicity in design easy to use and operate while enabling site locations and operators to self-support and maintain.
cleaning path 11 in / 280 mm
productivity (per hour) theoretical max 10,505 ft2 / 976 m2
estimated coverage 6,875 ft2 / 639 m2
max speed 2.17 mph / 3.5 kmh
brush rpm 160
brush/pad pressure 26 lbs / 12 kg
solution tank capacity 1.3 gal / 5 l
recovery tank capacity 1.3 gal / 5 l
battery run time (up to hours)* 50 mins (standard) | 75 mins (optional)
battery voltage 36
length x width x height (handle in upright position) 24.21 x 16.24 x 41.29 in / 615 x 412.5 x 1049 mm
length x width x height (storage position with handle folded down) 30.31 x 16.24 x 15.7 in / 770 x 412.5 x 399 mm
weight (with batteries) 43.65 lbs (standard) - 44.53 lbs (optional) / 19.8 kg (standard) - 20.2 kg (optional)
sound level (operator’s ear)** 63 dba
Parts
Can't find what you need? Click here or call 1-800-USA-CLEAN
In the market for a new machine? You can find quality new and reconditioned floor care equipment at one of our vendor partners:
Need a professional? We offer service both virtually and in person.
Learn more
Diagrams
- View all diagrams
- - Batteries, Brushes, and Charger
- - Pad Holders
- - Pads
- Brush Motor Assembly
- Brushes, Pad Driver, and Pads
- Cable Assembly
- Control Handle Assembly
- Frame and Battery Assembly
- Solution Pump Assembly
- Squeegee Assembly
- Squeegee Diverter Valve Assembly
- Tank Assembly
- Vacuum Motor Assembly
- Wiring Diagram
