A compact walk-behind sweeper with a sweeping path of 69cm. Quick and effortless high performance at low cost, effective on hard surfaces from concrete, vinyl tile and terrazzo, to wood and asphalt. Large wheels positioned outside the frame enable you to travel over stairs and curbs. The main brush sweeps directly into the debris hopper, the side brush removes dirt and debris from edges and corners and can be raised up to assist manoeuvrability in confined areas.

• Sweeps up to 2000m2 per hour
• Direct throw sweeping system
• Sweeps all kind of hard flooring
• Works on wet and dry surfaces, indoors and outdoors
• Fume-free & quiet operation
• No-tool brush adjustment

Working width (single side brush) cm 69
Working width (dual side brushes) cm n/a
Dimensions (lxwxh) cm 115x76x90
Machine weight (net) kg 21
Area coverage theoretical (max) m2/h 2760
Area coverage practical (max) m2/h 1540
Length main brush x dia cm 48 x 20
Diameter side brush cm 31
Sweeping principle direct throw
Transaxle drive yes/no no
Panel filter capacity m 20
Airflow L/s n/a
Hopper capacity, volume L 30
Hopper capacity, weight kg 25
Hopper dump height cm n/a
Power source n/a
Total power consumption W n/a
Protection class I/II/III n/a
Sound level (DIN45635) dB(A) < 60
Transport speed km/h n/a
Working speed km/h 2.5
Climbing capacity % n/a
Turning circle cm 140
