Low speed Heavy Duty single disc machine

Key advantages:
• Effectiveness
• Robustness
• Ergonomics
• Simplicity

Effectiveness
A stiff metal chassis, increased weight of the machine and an extremely powerful motor deliver excellent mechanical scrubbing action. Ideal for heavy duty applications, such as floor stripping, marble crystallization or wood treatment, the Taski Ergodisc HD delivers best in class effectiveness. The low height of the brush housing and motor allows cleaning under obstacles- while the brush speed of 150 rpm delivers a very even surface texture and reduces splashing of cleaning solution.

Robustness
The rugged construction of the machine with a high torque motor makes it very robust and durable. The planetary gear transmission required very little maintenance and eliminates the potential issue of wearing or slipping transmission belts.

Ergonomics
While settings standards in effectiveness, this machine also improves the operator's working conditions through a number of unique features. The anatomically formed and height adjustable handle has a unique hand protection. In combination with a low vibration level and reduced noise emission that allows for long working hour with tiredness.

Simplicity
Transportation and storage of the machine is very simple, thanks to the large soft wheels, foldable handle and the option to remove the additional weight. Attaching accessories does not require any tools. This reduces the need for operator training to minimum.

Tool diameter 43 cm
Motor height 35 cm
Speed 150 RPM
Height of brush housing 8 m
Motor 230 V / 50 Hz
Protection class II
Nominal consumption 1.1 kW
Test Certificates CB-Protocol
Weight 54 kg
Machine housing/chassis Cast Aluminium
Option: additional weight 10 kg
Transmission Planetary Gear
Cable length 15 meters
