The compact brush-squeegee unit ideally adapts to uneven or structured floors and allows forward and reverse cleaning. The squeegee pressure remains constant, independent of brush wear and closely follows the floor profile. This ensures efficient water pick up and fast drying.
Cleaning of hard-to-access areas
A special suspension arrangement allows free side floating of the brush-squeegee unit and therefore enables cleaning and removal of the solution along walls and edges. The low height of the machine also allows easy cleaning under tables and racks.
Simple and ergonomic operation
The removable recovery tank can be lifted off for draining and due to it's wide opening, can be easily cleaned. The cleaned recovery tank can also be used to fill the solution tank with fresh water.
Easy storage
A parking wheel, which can be operated with a foot pedal, relieves pressure on the brush-squeegee unit. In addition a collapsible handle allows space saving storage.
Theoretical performance: 1225 m2/h
Working width: 35 cm
Squeegee width: 46 cm
Solution tank (nominal): 10 l
Recovery tank (nominal): 10 l
Nominal consumption: 1300 W
Rated voltage: 230-240 V / 50 Hz
Machine weight ready for use: 49 kg
Dimensions (L x W x H): 660x380x510 mm
Turning radius: 0.8 m
Brush system: Roller brush
Brush pressure: 12 kg
Working speed: 3-4 km/h
Cable length: 15 m
Sound level: 67 dB(A)
Splash water protection: IPX 4
Protection class: I
Approvals: TÜV, ÖVE Interactive Service Guide
TASKI by Diversey COMBIMAT 300 Parts and Support
Perfect cleaning and fast drying
The compact brush-squeegee unit ideally adapts to uneven or structured floors and allows forward and reverse cleaning. The squeegee pressure remains constant, independent of brush wear and closely follows the floor profile. This ensures efficient water pick up and fast drying.
Cleaning of hard-to-access areas
A special suspension arrangement allows free side floating of the brush-squeegee unit and therefore enables cleaning and removal of the solution along walls and edges. The low height of the machine also allows easy cleaning under tables and racks.
Simple and ergonomic operation
The removable recovery tank can be lifted off for draining and due to it's wide opening, can be easily cleaned. The cleaned recovery tank can also be used to fill the solution tank with fresh water.
Easy storage
A parking wheel, which can be operated with a foot pedal, relieves pressure on the brush-squeegee unit. In addition a collapsible handle allows space saving storage.
Theoretical performance: 1225 m2/h
Working width: 35 cm
Squeegee width: 46 cm
Solution tank (nominal): 10 l
Recovery tank (nominal): 10 l
Nominal consumption: 1300 W
Rated voltage: 230-240 V / 50 Hz
Machine weight ready for use: 49 kg
Dimensions (L x W x H): 660x380x510 mm
Turning radius: 0.8 m
Brush system: Roller brush
Brush pressure: 12 kg
Working speed: 3-4 km/h
Cable length: 15 m
Sound level: 67 dB(A)
Splash water protection: IPX 4
Protection class: I
Approvals: TÜV, ÖVE
The compact brush-squeegee unit ideally adapts to uneven or structured floors and allows forward and reverse cleaning. The squeegee pressure remains constant, independent of brush wear and closely follows the floor profile. This ensures efficient water pick up and fast drying.
Cleaning of hard-to-access areas
A special suspension arrangement allows free side floating of the brush-squeegee unit and therefore enables cleaning and removal of the solution along walls and edges. The low height of the machine also allows easy cleaning under tables and racks.
Simple and ergonomic operation
The removable recovery tank can be lifted off for draining and due to it's wide opening, can be easily cleaned. The cleaned recovery tank can also be used to fill the solution tank with fresh water.
Easy storage
A parking wheel, which can be operated with a foot pedal, relieves pressure on the brush-squeegee unit. In addition a collapsible handle allows space saving storage.
Theoretical performance: 1225 m2/h
Working width: 35 cm
Squeegee width: 46 cm
Solution tank (nominal): 10 l
Recovery tank (nominal): 10 l
Nominal consumption: 1300 W
Rated voltage: 230-240 V / 50 Hz
Machine weight ready for use: 49 kg
Dimensions (L x W x H): 660x380x510 mm
Turning radius: 0.8 m
Brush system: Roller brush
Brush pressure: 12 kg
Working speed: 3-4 km/h
Cable length: 15 m
Sound level: 67 dB(A)
Splash water protection: IPX 4
Protection class: I
Approvals: TÜV, ÖVE
Parts
Can't find what you need? Click here or call 1-800-USA-CLEAN
Need a professional? We offer in person service.
Learn more
Diagrams
- View all diagrams
- - Pad Holders
- Brush Assembly
- Brush Motor Assembly - Series 02 - 07.1997 - 05.2004
- Brush Motor Assembly - Series 02 - After 05.2004
- Brushes
- Handle Assembly
- Power Cord Assembly
- Pump Assembly
- Squeegee and Brush Housing Assembly
- Squeegee Assembly
- Tank Assembly
- Tank Cover Assembly
- Vac Motor Assembly
- Wiring Diagram - Series 02 - 07.1997 - 05.2004
- Wiring Diagram - Series 02 - After 05.2004
Manuals
Bulletins
- Intellidose Electronics Revision_2017
- New Bumper Wheels_2003
- New Ceramic Axle_2016
- TASKI TSS Bulletin - Rating Plate Breakdown
