TASKI by Diversey balimat 2300 Parts and Support

• Parts
• Diagrams
• Manuals

Compact battery sweeper

Key features & benefits:
• Perfect sweeping result on various floor types due to patented Twin roller system (TRS)
• Flexible use both indoors and out
• Increased productivity due to wide working width
• Compact size and agile handling allows perfect use in narrow areas
• Easy and simple to use whenever it's needed

Twin Roller System(TRS)
The patented Twin roller system (TRS) with counter rotating brushes transport the debris from one roller to the other and transport it upwards. Through a precisely defined guide plate above the roller intersection, the dirt is hurled by the cooperation of rollers above and guided backwards and pushed overhead into the dirt container. The side broom offset to the right supports the work of the roller brushes by sweeping debris from edges and corners of the roller brushes delivering perfect sweeping results in a single pass.

Flexibility
The Balimat 2300 is designed for indoor and outdoor use and allows cleaning on hard floors as well as carpet. Battery operation and brush assist makes cleaning simple and allow greatest flexibility when it comes to sweeping.

Easy and simple to use
Side broom and roller brushes are fully adjustable without any tools needed. The machine arrives ready to use and the dashboard uses icons which are self-explaining, so no operator training needed. Adjustable and foldable handle for comfortable and ergonomic use and easy storage.

Compact size
The compact size and the low height allow use of the machine in a narrow aisles and congested areas. In combination with the foldable handle, it's easy to clean under objects and to maneuver the machine around obstacles.

Dimensions (LxWxH) 92 x 65 x 56 cm
Weight 55 kg
Sweeping path width 620 mm
Main brush width 400 mm
Side brush diameter 300 mm
Hopper capacity 37 L
Battery capacity 12V , 50 Ah
Battery run time Up to 3h
Total power consumption 12 VDC, 230 W, 12.6 A
Battery charger 100-240VAC 8A
Sound pressure level 62 dB(A)
Protection grade IPX3
