The most demanding jobs demand the big PAS40R-- Fully equipped to handle the biggest jobs!

The Powr-Flite PAS40R battery operated auto scrubber is designed specifically for large areas and features the convenience of ride-on comfort. Operators will be able to clean larger areas with fewer breaks and with less fatigue. The PAS40R is extremely simple to use and maneuvers easily around corners and other obstructions. The PAS40R provides the convenience of cleaning and drying in one simple pass. The curved 46 inch squeegee dries floor even on tight turns. The PAS40R is built to last, providing maximum life with low operating cost. The rugged frame is made of 30/10 sheet steel with a polyethylene constructed housing. Safety features protect against misuse and accidents.

¦ 64,000 square feet per hour cleaning ratio
¦ 4-6 hours runtime
¦ Twin vacuum motors
¦ 46" curved squeegee
¦ 64,000 square feet per hour

Cleaning Sq. Ft. Per Hour 64,000
Solution Tank 45 gallons
Recovery Tank Capacity 45 gallons
Cleaning Width 40 inches
Brush Diameter (2) 20 inches
Brush Pressure 220-440 lbs.
Brush Speed 225 RPM
Brush Motor (2) 3/4 hp 36 volt
Squeegee Width 46 inches
Traverse Motor 36 volt, variable speed
Vacuum Motor 3 stage by-pass, 2 each 1/2 hp
Supply Voltage 36 volt deep cycle (batteries not included)
Battery Storage Area 23" x 21" x 16"
Continuous Run Time 6 hours
Operating Time 4 - 6 hours
Dimensions 70" x 41" x 67"
Operations Control Security, safety key locked , key locked
Warranty 10 yrs housing 1 year parts
Weight 880 lbs.
Shipping Weight 980 lbs.
