Pacific Floorcare Z20T Parts and Support

• Parts
• Diagrams
• Manuals

One of Pacific’s most popular scrubbers, the single disk Z20T and Z20BA models suit a variety of cleaning applications and facility sizes. The Z20T/Z20BA feature simple controls and easy to read gauges that provide operators with a high comfort level. The Z20T/Z20BA auto scrubbers’ 20" cleaning path, 16-gal tank capacity and 30" squeegee make them a mainstay of almost any hard floor care program. The unique hands free pad on/off feature makes pad changes as easy as pushing a button. The Z20BA is a brush assist model and the Z20T comes standard with a transaxle. Add the Z20BA or the Z20T auto scrubbers to your floor care program today.

Cleaning Width 20"
Avg. Productivity 18,500 ft2/hr
Run Time 3.2 hrs.
Brush Diameter(1) 20" disk
Brush RPM 250 rpm
Brush Pressure 55 lbs
Brush Motor 0.54 hp
Traction Motor 0.54 hp / (BA) NA
Drive Type Variable / (BA) Brush Assist
Vacuum Moto r0.6 hp
Solution Tank 16 gal.
Recovery Tank 19 gal.
Power System 24V DC
Battery Type (2) 12V 145 AH
Charger 24V 15 Amp
Length/Height 59"X41"
Width 21.7" (30" w/squeegee)
Wt. w/out Batteries 230 lbs. / 220 lbs.
