The WAV-26 is the newest and most advanced 26" wide area upright vacuum in the industry. With this upright vacuum, Pacific Floorcare ensured that you'd be equipped with latest features and specifications.

•Leading sound levels at <70 dBa
•33% larger bag capacity than competitive 26” upright vacuums
•Only upright wide area vacuum with HEPA filtration
•Only 26” upright wide area vacuum available with full set of on-board tools
•Only 26” upright wide area vacuum with CRI Seal of Approval
•Extended life due to rotomold construction and dual motor thermal protection.

Brush Drive System
Brush motor horsepower: .3 hp
Brush rpm: 1,200 rpm
Brush motor rpm: 2,500 rpm
Brush belt system: 5M V-belt
Brush width: 23 in
Brush bristle type: 4 row, 180° chevron
Brush diameter: 3 in
Productivity (per hour)*: 5,555 ft2
Brush height settings: 5 settings, hand lever adjusted
Vacuum System
Vacuum motor rating (hp/stage/etc.): 1.15 hp, 2-stage
Vacuum motor cfm: 94 cfm
Vacuum motor sealed water lift: 90 in
Cleaning path: 26 in
Recovery System
Vacuum filtration description: 5 microns (standard),
HEPA 99.97% to .3 microns (optional)
Vacuum bag description: Paper bags (standard),
Cloth shake out bag (optional)
Vacuum bag capacity: 14.1 qt, 15.5 L
Vacuum hose length: 3 ft - 5:1 stretch hose reaches 15 ft
(with on board tool kit)
Vacuum hose diameter: 1.5 in
Wand length: 3 ft
Electrical System
Voltage: 115 V
Power consumption amps: 9 amp
Power cord length / type: 50 ft, 14/3 SJT, safety yellow
Machine Specifications
Product length: 37 in (operating position)
Product width: 27 in
Product height: 37 in (operating position)
Product weight (w/cord): 67 lb
Sound level (operator’s ear): < 70 dBA
Approvals: Carpet & Rug Institute Bronze SOA
Construction: Rotationally molded polyethylene
