Rugged construction has been in Pacific’s floor machine DNA since the company’s origin. With this heritage and experience as its foundation, Pacific’s line up also brings new ingenuities to the industry’s most essential tool. From the industry’s first “safe start” indicator to its less than 58 dBa noise levels and an instantly adjustable handle, Pacific’s floor machines are Purpose Built® to be a step above the rest.

1.First-ever “safe start” indicator helps eliminate “taking off” at start-up
2.Instant adjustment from handle – no hard knobs or awkward levers
3.Unique and rugged wrap around cord clamp and flare strain relief
4.Single Speed: 175 rpm

-Floor scrubbing
-Finish stripping (with chemical)
-Light buffing
-Carpet bonneting
-Sanding and screening
-Many other project work tasks

Pad Drive System
Motor horsepower: 1.5 hp
Motor type: 66 FR, AC
Gear box: Triple-planetary
Pad speed rpm: 175 rpm
Pad diameter: 17 in
Equipped with pad driver: Yes
Productivity (per hour)*: 1,925 ft2
Electrical System
Voltage: 115 V
Power consumption amps: 15 amp
Power cord length / type: 50 ft, 14/3 STO, safety yellow
Safety approvals: ETL tested to UL/CSA standards
Machine Specifications
Product length: 22 in
Product width: 18 in
Product height: 45 in
Product weight (w/cord): 93 lb
Sound level (operator’s ear): < 58 dBA
Base construction: Dual-wall, rotationally molded impact resistant polyethylene
Handle construction: Welded structural steel tubing
Safety interlock on triggers: Yes
Vertical handle safety lockout: Yes
Handle construction: Welded structural steel tubing
Handle adjustment: Lever at operator position near triggers
Warranty
Base: 10 years
All other components**: 3 years
Labor: 1 year
