•Exceptional productivity. The large scrub deck and 30-gallon solution tank facilitates exceptional productivity with fewer trips to drain and refill the machine
•Built for daily commercial use. The Wrangler 2730/3330's rugged construction ensures it is ready to work when you need it.
•Simple controls. Operated by just a dew switches and mechanical levers, custodians can be ready to clean with just a few minutes of training.
Cleaning Path 27 in (69 cm)
Brush/Pad 2 x 14 in
Solution Tank 30 gal (114 L)
Recovery Tank 32 gal (125 L)
Solution Flow Rates 0 to 1.0 GPM, manual valve
Brush Motor (HP) 0.75 (560 W)
Brush Motor (RPM) 200
Pad Pressure (Lbs) 100, 200
Vacuum Motor (HP) 0.75 (560 W)
Vacuum Motor (CFM) 73
Water Lift (in) 70
Drive Motor (HP) 0.5 (370 W)
Drive Wheel 10” x 4”
Wheel Material Non-marking rubber
Drive Speed Forward: Up to 260 ft/min Reverse: Up to 175 ft/min
Batteries, Quantity 6 x 6V
Batteries, Type and Size 220 AH AGM, 235 AH Wet, 330 AH AGM or 350 AH Wet
Run Time (Hours)
220 AH AGM up to 3.0
235 AH Wet up to 3.2
330 AH AGM up to 3.7
350 AH Wet up to 4.0
Sound Level (dBA) 66
Productivity (ft2/hr)
Theoretical 35,800
Practical 16,600
Dimensions L x W x H 64 x 30 x 42 in 163 x 76 x 107 cm
Weight (Lbs)
Shipping Machine
220 AH 902 873
235 AH 934 905
330 AH 1,110 1,081
350 AH 1,086 1,057
NSS Enterprises WRANGLER 2730 Parts and Support
improve productivity with nss's largest walk-behind scrubbers. perfect for large areas in retail, healthcare, hospitality and light industrial facilities. simple operation and durable construction make this scrubber a superior choice for your cleaning program.
•exceptional productivity. the large scrub deck and 30-gallon solution tank facilitates exceptional productivity with fewer trips to drain and refill the machine
•built for daily commercial use. the wrangler 2730/3330's rugged construction ensures it is ready to work when you need it.
•simple controls. operated by just a dew switches and mechanical levers, custodians can be ready to clean with just a few minutes of training.
cleaning path 27 in (69 cm)
brush/pad 2 x 14 in
solution tank 30 gal (114 l)
recovery tank 32 gal (125 l)
solution flow rates 0 to 1.0 gpm, manual valve
brush motor (hp) 0.75 (560 w)
brush motor (rpm) 200
pad pressure (lbs) 100, 200
vacuum motor (hp) 0.75 (560 w)
vacuum motor (cfm) 73
water lift (in) 70
drive motor (hp) 0.5 (370 w)
drive wheel 10” x 4”
wheel material non-marking rubber
drive speed forward: up to 260 ft/min reverse: up to 175 ft/min
batteries, quantity 6 x 6v
batteries, type and size 220 ah agm, 235 ah wet, 330 ah agm or 350 ah wet
run time (hours)
220 ah agm up to 3.0
235 ah wet up to 3.2
330 ah agm up to 3.7
350 ah wet up to 4.0
sound level (dba) 66
productivity (ft2/hr)
theoretical 35,800
practical 16,600
dimensions l x w x h 64 x 30 x 42 in 163 x 76 x 107 cm
weight (lbs)
shipping machine
220 ah 902 873
235 ah 934 905
330 ah 1,110 1,081
350 ah 1,086 1,057
•exceptional productivity. the large scrub deck and 30-gallon solution tank facilitates exceptional productivity with fewer trips to drain and refill the machine
•built for daily commercial use. the wrangler 2730/3330's rugged construction ensures it is ready to work when you need it.
•simple controls. operated by just a dew switches and mechanical levers, custodians can be ready to clean with just a few minutes of training.
cleaning path 27 in (69 cm)
brush/pad 2 x 14 in
solution tank 30 gal (114 l)
recovery tank 32 gal (125 l)
solution flow rates 0 to 1.0 gpm, manual valve
brush motor (hp) 0.75 (560 w)
brush motor (rpm) 200
pad pressure (lbs) 100, 200
vacuum motor (hp) 0.75 (560 w)
vacuum motor (cfm) 73
water lift (in) 70
drive motor (hp) 0.5 (370 w)
drive wheel 10” x 4”
wheel material non-marking rubber
drive speed forward: up to 260 ft/min reverse: up to 175 ft/min
batteries, quantity 6 x 6v
batteries, type and size 220 ah agm, 235 ah wet, 330 ah agm or 350 ah wet
run time (hours)
220 ah agm up to 3.0
235 ah wet up to 3.2
330 ah agm up to 3.7
350 ah wet up to 4.0
sound level (dba) 66
productivity (ft2/hr)
theoretical 35,800
practical 16,600
dimensions l x w x h 64 x 30 x 42 in 163 x 76 x 107 cm
weight (lbs)
shipping machine
220 ah 902 873
235 ah 934 905
330 ah 1,110 1,081
350 ah 1,086 1,057
