•Designed for applications from 10,000 to 30,000 square feet, these Wranglers are perfectly sized for small office buildings, convenience stores, and nursing homes. They are also ideal for larger facilities with confined areas, such as grocery store checkout aisles, school cafeterias, commercial kitchens, and hospitals rooms.
•Wrangler compacts feature a 10-gallon solution tank and an oversized 12-gallon recovery tank, which allows room for foam, helping protect the vacuum motor for moisture.
•The curved squeegee features a breakaway assembly to prevent damage when it inadvertently catches on any fixed object. Reconnecting is as simple as hand tightening two knobs.
•To simplify pad changing, a foot latch at the front of the machine allows the body to tilt up and back. This also provides easy access to the batteries and all internal components.
•Wrangler compacts are available with a 17 inch or 20 inch scrubbing path in battery-powered (AB) models.
•The on-board charger, standard on all battery-powered Wrangler automatic scrubbers, allows the batteries to be charged anywhere an electrical outlet is available.
Brush Pad 17 in (43 cm)
Pad Drive Motor
Type Permanent magnet, 24V, 0.75 HP
Speed 200 RPM
Vacuum Motor
Type 2-stage bypass peripheral discharge
HP 0.5 HP
CFM 65.1 (1.8 m3)
Waterlift 49 in (124 cm)
Batteries Two 12V, 115 AH, 2.5 hour runtime
Tank Capacity
Solution 10 gal (38 L)
Recovery 12 gal (45.5 L)
Squeegee Curved squeegee standard, swing type with breakaway feature
Construction
Body Rotomolded polyethylene tanks and body, hinged on steel frame
Wheels Two 8 in (20 cm) non-marking wheels
Casters Two front 3 in (7.6 cm) ball-bearing swivel casters
Float Ball Type
Sound Level 66 dBA @ operator
Dimensions
Length 44.5 in (113 cm)
Width 19 in (48 cm)
Body Weight 35.5 in (90 cm)
Handle Weight 43.8 in (111 cm)
Shipping Class 125
Warranty 3 year limited, 10 years poly parts
NSS Enterprises WRANGLER 2010 Parts and Support
ergonomic design, simple operation and a compact body make the wrangler 1710 and wrangler 2010 the best values in small scrubbers.
•designed for applications from 10,000 to 30,000 square feet, these wranglers are perfectly sized for small office buildings, convenience stores, and nursing homes. they are also ideal for larger facilities with confined areas, such as grocery store checkout aisles, school cafeterias, commercial kitchens, and hospitals rooms.
•wrangler compacts feature a 10-gallon solution tank and an oversized 12-gallon recovery tank, which allows room for foam, helping protect the vacuum motor for moisture.
•the curved squeegee features a breakaway assembly to prevent damage when it inadvertently catches on any fixed object. reconnecting is as simple as hand tightening two knobs.
•to simplify pad changing, a foot latch at the front of the machine allows the body to tilt up and back. this also provides easy access to the batteries and all internal components.
•wrangler compacts are available with a 17 inch or 20 inch scrubbing path in battery-powered (ab) models.
•the on-board charger, standard on all battery-powered wrangler automatic scrubbers, allows the batteries to be charged anywhere an electrical outlet is available.
brush pad 17 in (43 cm)
pad drive motor
type permanent magnet, 24v, 0.75 hp
speed 200 rpm
vacuum motor
type 2-stage bypass peripheral discharge
hp 0.5 hp
cfm 65.1 (1.8 m3)
waterlift 49 in (124 cm)
batteries two 12v, 115 ah, 2.5 hour runtime
tank capacity
solution 10 gal (38 l)
recovery 12 gal (45.5 l)
squeegee curved squeegee standard, swing type with breakaway feature
construction
body rotomolded polyethylene tanks and body, hinged on steel frame
wheels two 8 in (20 cm) non-marking wheels
casters two front 3 in (7.6 cm) ball-bearing swivel casters
float ball type
sound level 66 dba @ operator
dimensions
length 44.5 in (113 cm)
width 19 in (48 cm)
body weight 35.5 in (90 cm)
handle weight 43.8 in (111 cm)
shipping class 125
warranty 3 year limited, 10 years poly parts
•designed for applications from 10,000 to 30,000 square feet, these wranglers are perfectly sized for small office buildings, convenience stores, and nursing homes. they are also ideal for larger facilities with confined areas, such as grocery store checkout aisles, school cafeterias, commercial kitchens, and hospitals rooms.
•wrangler compacts feature a 10-gallon solution tank and an oversized 12-gallon recovery tank, which allows room for foam, helping protect the vacuum motor for moisture.
•the curved squeegee features a breakaway assembly to prevent damage when it inadvertently catches on any fixed object. reconnecting is as simple as hand tightening two knobs.
•to simplify pad changing, a foot latch at the front of the machine allows the body to tilt up and back. this also provides easy access to the batteries and all internal components.
•wrangler compacts are available with a 17 inch or 20 inch scrubbing path in battery-powered (ab) models.
•the on-board charger, standard on all battery-powered wrangler automatic scrubbers, allows the batteries to be charged anywhere an electrical outlet is available.
brush pad 17 in (43 cm)
pad drive motor
type permanent magnet, 24v, 0.75 hp
speed 200 rpm
vacuum motor
type 2-stage bypass peripheral discharge
hp 0.5 hp
cfm 65.1 (1.8 m3)
waterlift 49 in (124 cm)
batteries two 12v, 115 ah, 2.5 hour runtime
tank capacity
solution 10 gal (38 l)
recovery 12 gal (45.5 l)
squeegee curved squeegee standard, swing type with breakaway feature
construction
body rotomolded polyethylene tanks and body, hinged on steel frame
wheels two 8 in (20 cm) non-marking wheels
casters two front 3 in (7.6 cm) ball-bearing swivel casters
float ball type
sound level 66 dba @ operator
dimensions
length 44.5 in (113 cm)
width 19 in (48 cm)
body weight 35.5 in (90 cm)
handle weight 43.8 in (111 cm)
shipping class 125
warranty 3 year limited, 10 years poly parts
