SIDEWINDER 27

4

• Parts
• Diagrams
• Docs

For quick retrieval of trash and litter, the Sidewinder 27 is ideal for indoor or outdoor use, in damp or dry conditions.

•The 27-inch sweeping path makes quick work of hard surface surface clean-up jobs-five times faster than push brooms
•The removable hopper makes emptying the machine quick and easy
•The 12-inch (30.5 cm) side broom assures dirt along walls and curbs is picked up by the main brush
•The pressure adjustment knobs, one for the side brooms and another for the main broom, allow the operator to keep the Sidewinder 28 working at the proper brush height
•Lightweight and maneuverable, the Sidewinder 27 is a natural for shopping malls, movie theaters, supermarkets, warehouses, and parking lots, where litter removal is necessary.

Sweeping Path 27 in (68.6 cm) main and side broom combined
Main Broom 19 in (48.3 cm)
Side Broom 12 in (30.5 cm) overlaps main brush
Drive Manual
Dust Control Rubber seals
Construction
Frame Injection-molded polyethylene
Hopper Injection-molded polyethylene
Hopper Capacity 12 gal (40 L)
Main Broom Nylon
Side Broom Nylon
Wheels Two 11 in (30 cm)
Caster 3 in (8 cm)
Switches & Controls Separate brush height adjustment for each broom
Dimensions
Handle Height 37 in (94 cm)
Body Height 10 in (25.5 cm)
Length 54.5 in (138.5 cm)
Width With Broom 31.5 in (80 cm)
Weight
Machine 44 lbs (20 kg)
Shipping 47 lbs (21.3 kg)
Shipping Class 100
Warranty 1 year limited
Productivity 31,000 sq ft/hour (2,880 m2)
