RALLY 1200

2

• Parts
• Diagrams

Clean bathrooms eliminate the opportunity for complaints and create an overall feeling of trust with your company or institution. To completely manage the soil and bacteria that build up in bathrooms, grout cleaning is a must. The Rally 1200 gives you the ability to maintain new tile and improve neglected tile and grout to a like-new condition.

•The Rally 1200's Hard Surface Tool uses two streams of 1200 PSI water to turn the spray bar at up to 1400 RPM. This high pressure spray helps remove soil from the tile and grout. A vacuum shroud surrounding the tool pulls the dirty water into the recovery tank.
•Continuous water supply keeps your staff productive on large jobs. Use standard garden hoses to supply water to and drain water from the Rally 1200.
•Not just for hard floors. Reduce the pressure on the Rally 1200 and it can be used as a cold water carpet extractor.
•Easy maintenance. By removing a single bolt, the tanks on the rally 1200 can be tilted back, revealing the inner workings of the machine.

Solution Tank 12 Gallons (45 L)
Recovery Tank 12 Gallons (45 L)
Solution Pump Adjustable, 400 - 1200 PSI
Accessory Valve Quick disconnect, all brass
Vacuum Motor 2-stage, 2.1 HP (1565 Watts)
Water Lift 140 inches (355 cm)
Hoses 25 ft (7.6 m)
Input Voltage 120V or 240V
Construction
Tanks Rotomolded polyethylene
Wheels Two 10-in (25 cm)
Casters Two 4-in (10 cm)
Cord Two 25 ft (7.6 m) 12-3 SJTW
Sound Level 75 dBA
Dimensions L x W x H 39 x 26 x 17 inches 99 x 66 x 43 cm
Weight 150 lbs (68 kg)
Warranty 1 year parts, 10 years on tanks.
Productivity 500 ft2/hr (47 m2/hr)
