Big jobs require big machines. Boost productivity with the Pony 20 SCA. Extract up to four times faster than a tank extractor. The self-propelled Pony 20 SCA helps your staff stay productive longer, an essential feature for large jobs.

•The Pony 20 SCA is designed for large extraction jobs. A built in pump sprayer can be used to pretreat high-traffic areas and the 20 gallon tank provides plenty of clean solution between refills.
•More than just a carpet extractor. Add tools and hoses to the Pony 20 to extend its capabilities to include cleaning upholstery and stairs.
•Easy maintenance. The Pony 20's spray bar can be quickly disconnected and cleaned. Moreover, the Pony 20's body is hinged and can tilt forward allowing access to internal components.

Cleaning Path 22” (56 cm) Cylindrical Brush
Solution Tank 20 Gallons (76 L)
Recovery Tank 20 Gallons (76 L)
Solution Pump 100 PSI
Spray Wand Built in with 6 foot hose
Vacuum Motor
Type 3-stage, 1.75 HP (1300 Watts)
Water Lift 125 in (318 cm
Drive Motor
Power 0.06 HP (45 Watts)
Drive Speed 0 to 100 ft/s (30 m/s)
Brush Motor
Power 0.25 HP (185 Watts)
RPM 2100
Input Voltage 120V or 240V
Construction
Tanks Rotomolded polyethylene
Base Welded steel
Housing Mounted on hinges
Spray Jets Stainless Steel, snap-in jets, Qty 5
Wheels Two 8-in (20 cm) roller bearing
Casters Two 4-in (10 cm) ball bearing swivel
Vacuum Shoe Cast aluminum with steel plate
Cord 12-3 SJT, twist-lock, 75 ft (23 m)
Sound Level 75 dBA
Dimensions 47 x 24 x 41 inches
L x W x H 119 x 60 x 104 cm
Weight
Machine 165 lbs (73 kg)
Shipping 204 lbs (93 kg)
Warranty 3 years parts, 10 years on tanks.
Productivity 4,183 ft2/hr (389 m2/hr)
