For quick, effective carpet vacuuming, the Pacer 14 UE and Pacer 18 UE combine cleaning power and ease of operation to make them the ideal choice in two-motor uprights.

-One motor for suction power and a second motor to drive the brush for the most effective cleaning performance.
-Ergonomic design features reduce operator fatigue.
-Enclosed ergonomic handle allows a relaxed grip.
-Large built-in carrying handle makes transport easy.
-3-stage filtration system enhances IAQ.
-Poly-lined two-ply paper filter bag contains the vacuumed dirt.
-Stage-two motor filter provides added filtration in the event of a
tear in the filter bag.
-HEPA exhaust filter traps additional particles and carbon brush dust created by the vacuum motor.
-Brush motor shuts off when the wand is in use for detail cleaning,
protecting the carpet from brush burn.
-Removable suction tube makes clearing clogs simple.

BrushSpiral brush with replaceable strips
Vacuum Motor2-stage, 10.5 amps @ 120V (1000 watts)
Type4.4 amps @ 240V (1000 watts)
Air FlowMaximum 91 CFM (43 L/sec)
Waterlift84 in
Brush Motor1.4 amps @ 120V, 0.8 amps @ 240V
Filtration3-stage—top-filled, two-ply poly-lined filter, motor filter, and HEPA exhaust filter.
Switches & ControlsRocker on/off switch and bag full
indicator light
Cord 40 ft (12.2 m) 18-3 SJT safety yellow
ConstructionComposite polypropylene body and
base
Sound Level
14 UE65 dBA
18 UE66 dBA
Bag Capacity5 quarts dry (4.75 L)
Cleaning Path
14 UE14 in (36 cm)
18 UE18 in (46 cm)
Dimensions
Height48.75 in (125 cm)
Width 14 UE14.5 in (39 cm)
Width 18 UE18.5 in (50 cm)
Weight
14 UE21 lbs (9.5 kg)
18 UE22 lbs (10 kg)
Shipping Weight
14 UE27 lbs (12.5 kg)
18 UE28 lbs (13 kg)
Shipping Class100
Warranty1 year, 2 years on motors and PC board
Productivity
14 UE4,000 sq ft/hour (372 m2)
18 UE5,130 sq ft/hour (465 m2)
