Incorporating the latest innovations, the Pacer 112 UE and 115 UE
are single-motor upright vacuums designed for reliability.

•Lightweight, ergonomic design reduces operator fatigue.
• Variable handle adjustment for different height users.
• Closed handle allows a relaxed grip. makes transport easy
•Powerful 1.5 HP motor and Chevron-style brush for thorough cleaning.
•HEPA filter standard. Optional cloth and fleece bags are available.
•Thorough three-step filtration: two-ply bag, motor filter, and HEPA filter.
•Reliable mechanical clutch disconnects brush when jammed.
•Detachable suction tube makes clearing clogs simple.
•Molded rubber bumper protects fixtures and furniture.
•No expensive electronic controls to repair or replace.
•Durable polypropylene body and base stand up to commercial use.
•Simple cord wrap release for quick access.

Brush : Chevron style brush
Motor:2-stage, 9 amps @ 120V (1150 watts)
Type: 1.5 HP
Air Flow:Maximum 102 CFM (48 l/sec)
Waterlift: 84 in
Filtration: 3-stage — Top-filled, two-ply polylined filter bag, motor filter, and HEPA exhaust filter
Switches & Controls: Rocker on/off switch and bag full indicator light
Cord: 40 ft (12 m) 18-3 SJT safety yellow
Construction: Composite Polypropylene body and base
Bag Capacity: 5.1 quarts dry (4.8 l)
Cleaning Path: 115 UE: 15 in (38 cm)
Sound Level: 67 dBA
Dimensions:
Height:48.75 in (125 cm)
Width 112 UE:12.5 in (32 cm)
Weight 112 UE:17.4 lbs (7.9 kg)
Shipping Weight:23 lbs (10.4 kg) max
Warranty:2 years, including belt, excluding wear items
