AVENGER 18AX

• Parts
• Diagrams
• Manuals

With large 18-gallon tanks and a 3/4 hp drive motor, the Avenger AV 18AX can tackle even the biggest commercial job.

With the optional patented onboard “Smart Kit,” the pump can be used as an automatic pre-spray
system with the chemical injected downstream (of the pump) so only water flows through it,
preventing any buildup.

Key Features

Rugged two piece roto moulded polyethylene
Powerful 1.8 Hp 3 stage vacuum motor provides 135" waterlift and 95 CFM of airflow
Features a 130 PSI diaphragm pump with bypass
Excellent for both interim maintenance and restorative cleaning
Efficient forward motion allows upwards of 4000 sq.ft./ hour to be cleaned
Easy access removeable spray bar with twist off jets
The lock down vacuum shoe ensures consistent pressure on the carpet at all times
The large 18 gallon tanks enable it to tackle even the biggest commercial jobs
Lightweight and easy to transport with the upper and lower tanks detaching into two separate units
Accepts all optional accessories including the HT1800 heater and Smart Kit

Solution Capacity:18 GALLON
Recovery Capacity:18 GALLON
Cleaning Width:20"
Brush Motor:90W
Brush Size:18.25"
Brush Speed:600 RPM
Vacuum Motor Watts:1400 W
Vacuum Motor HP: 1.87 HP
Vacuum Motor Stages: 3 STAGE
Airflow (cfm): 95 CFM
Waterlift: 135"
Noise Level dB(A): 70
Flow Rate:1.2 GPM
Power Cord Length:50'
Pump Power:100 W
Pump Pressure:130 PSI
Pump Type:DIAPHRAGM
Traction Motor:3/4 HP
Voltage:120 V60 HZ
Weight:143.30 LBS
Length:36.22"
Width:19.68"
Height:40.15"
