The AVB 9X is well balanced and easy to use; the 16-inch brush ensures it can handle the toughest of jobs. The high water lift motor provides excellent water recovery; in most cases carpets can dry in less than one hour. The float shut-off ensures water never reaches the vacuum motor and the four jet spray bar provides a consistent spray pattern with no streaking.

Key Features

With a sound level of only 60 Db(A) the AVB9X can be used in even the most sensitive areas.
Rugged two piece roto moulded polyethylene
Powerful 1.8 Hp vacuum motor with 2 year warranty providing excellent water recovery
Motor provides 135" waterlift and 95 CFM of airflow
Features a 130 PSI pump with quick release spray jets
The 16" brush provides excellent agitation on those tight areas needing a deeper clean
Lightweight and easy to transport with the upper and lower tanks detaching into two separate units
Fully adjustable water flow allowing for low moisture cleaning or full restoration cleaning.

Solution Capacity:9 GALLON
Recovery Capacity:9 GALLON
Cleaning Width:15.75"
Brush Motor:1X90W
Brush Speed:600 RPM
Vacuum Motor Watts:1400 W
Vacuum Motor HP:1.87 HP
Vacuum Motor Stages:3 STAGE
Airflow (cfm):95 CFM
Waterlift:135"
Noise Level dB(A): 60
Flow Rate:1.2 GPM
Power Cord Length:50'
Pump Power:100 W
Pump Pressure:130 PSI
Pump Type:DIAPHRAGM
Voltage:120 V60 HZ
Weight:110 LBS
Length:31.49"
Width:15.75"
Height:36.61"
