Nobles SCOUT 3B Parts and Support

• Parts
• Diagrams
• Manuals
• Docs

It’s flexible
The Scout 3B is well suited for indoor and outdoor cleaning on hard and soft floor surfaces. Battery operation and broom drive makes cleaning simple anytime, anywhere.

It's efficient
Dual side brushes increase the sweeping path to 34 in / 870 mm, and a large 1.8 ft3 / 50 L hopper saves you trips to the dumpster, which gives you more time for cleaning.

It’s durable
Major components field-proven in commercial applications for 10 years. Wrapped front bumper design helps prevent high-impact damage to body and side brushes.

It’s easy
Simple, no-tool side brush adjustments and easy-to-use operation mean less time training and more time cleaning. The contoured handle is padded and ergonomically designed for optimal operator comfort.

Cleaning path 34 in 870 mm
Productivity
Practical (per ISSA 540 cleaning times) 18,750 ft2/hr / 1,740 m2/hr
Brush speed 378 rpm
Main brush length 20 in 500 mm
Side brush diameter 13 in 320 mm
Debris hopper volume capacity 1.8 ft3 50 L
Power transmission Maintenance free, high
performance belt drive
Battery w/charger on board 12 V AGM
Dust filtration 99.97 @ .3 microns
Filter area 14 ft2 / 1.3 m2
Product length 43 in 1092 mm
Product width 30 in 760 mm
Product height 55.7 in 416 mm
Product weight w/battery 123 lb 56 kg
Product weight w/o battery 101 lb 46 kg
Sound level (operator’s ear) 65 dBA
