Scrub Head Type: Disc
Scrub Path: 32 in (81 cm)
Max Productivity @ 3 mph 42,240 ft2/hr (3,924 m2/hr)
Max Productivity @: 1.5 mph21,120 ft2/hr(1,962 m2/hr)
Brush Size: (2) 16 in (41 cm)
Scrub Pressure
Regular Scrub: max 90 lb (41 kg)
Heavy Scrub: max 175 lb (79 kg)
Extreme Scrub: max 250 lb (113 kg)
Brush Speed: 220 rpm
Solution Flow Rate
Regular Scrub: 0.30 gal/min (1.1 L/min) or 100 minutes per solution tank – ALL MODELS
Heavy Scrub: 0.60 gal/min (2.3 L/min) or 50 minutes per solution tank – ALL MODELS
Extreme Scrub: 0.90 gal/min (3.4 L/min) or 33 minutes per solution tank – ALL MODELS
Squeegee Width : 41.9 in (106 cm)
Dimensions (w/o squeegee): W = 33 in (83 cm)L = 62.5 in (159 cm)H = 45 in (114 cm)
Weight w/ Std. Batteries: 914 lb (415 kg)
Weight w/ Std. Batteries: 914 lb (415 kg) 914 lb (415 kg) 946 lb (430 kg) 946 lb (430 kg)
Voltage: 36 V – ALL MODELS
Power Source: (6) 6 V batteries (wet acid and gel cell available) – ALL MODELS
Available Chargers: 36 V, 20 amp free standing or 36 V, 21 amp onboard charger
Solution Control: Precision-Flow electric pump – AXP (Pulse control gravity feed - Warrior ST)
Solution Tank: 30 gal (114 L) – ALL MODELS
Recovery Tank: 30 gal (114 L) – ALL MODELS
Scrub Motors: (2) 0.75 hp (560 W) – ALL MODELS
Vacuum Motor: 0.75 hp (560 W) 3-stage – ALL MODELS
Sound Level: 69 dB A with sound suppression kit or 71 dB A standard – ALL MODELS
Drive System: 0.5 hp (375 W) variable forward and reverse, max speed = 3 mph (4.83 km/hr) – ALL MODELS
Gradeability: 16% transport, 5% scrubbing – ALL MODELS
Drive Wheels: (2) 13 in (33 cm) dia. foam-filled, gray non-marking – ALL MODELS
Nilfisk-Advance WARRIOR 32D Parts and Support
looking to boost cleaning productivity? consider the easy-to-maintain and operate advance warrior™ walk-behind scrubber. with tools-free interchangeable disc and cylindrical scrub decks, the warrior scrubber has the flexibility to scrub on multiple surfaces in one pass. the one-touch™ scrubbing controls minimize operator training and maximize cleaning performance. a single button automatically selects the right combination of solution flow and downward brush pressure for regular, heavy or extreme cleaning needs.
scrub head type: disc
scrub path: 32 in (81 cm)
max productivity @ 3 mph 42,240 ft2/hr (3,924 m2/hr)
max productivity @: 1.5 mph21,120 ft2/hr(1,962 m2/hr)
brush size: (2) 16 in (41 cm)
scrub pressure
regular scrub: max 90 lb (41 kg)
heavy scrub: max 175 lb (79 kg)
extreme scrub: max 250 lb (113 kg)
brush speed: 220 rpm
solution flow rate
regular scrub: 0.30 gal/min (1.1 l/min) or 100 minutes per solution tank – all models
heavy scrub: 0.60 gal/min (2.3 l/min) or 50 minutes per solution tank – all models
extreme scrub: 0.90 gal/min (3.4 l/min) or 33 minutes per solution tank – all models
squeegee width : 41.9 in (106 cm)
dimensions (w/o squeegee): w = 33 in (83 cm)l = 62.5 in (159 cm)h = 45 in (114 cm)
weight w/ std. batteries: 914 lb (415 kg)
weight w/ std. batteries: 914 lb (415 kg) 914 lb (415 kg) 946 lb (430 kg) 946 lb (430 kg)
voltage: 36 v – all models
power source: (6) 6 v batteries (wet acid and gel cell available) – all models
available chargers: 36 v, 20 amp free standing or 36 v, 21 amp onboard charger
solution control: precision-flow electric pump – axp (pulse control gravity feed - warrior st)
solution tank: 30 gal (114 l) – all models
recovery tank: 30 gal (114 l) – all models
scrub motors: (2) 0.75 hp (560 w) – all models
vacuum motor: 0.75 hp (560 w) 3-stage – all models
sound level: 69 db a with sound suppression kit or 71 db a standard – all models
drive system: 0.5 hp (375 w) variable forward and reverse, max speed = 3 mph (4.83 km/hr) – all models
gradeability: 16% transport, 5% scrubbing – all models
drive wheels: (2) 13 in (33 cm) dia. foam-filled, gray non-marking – all models
scrub head type: disc
scrub path: 32 in (81 cm)
max productivity @ 3 mph 42,240 ft2/hr (3,924 m2/hr)
max productivity @: 1.5 mph21,120 ft2/hr(1,962 m2/hr)
brush size: (2) 16 in (41 cm)
scrub pressure
regular scrub: max 90 lb (41 kg)
heavy scrub: max 175 lb (79 kg)
extreme scrub: max 250 lb (113 kg)
brush speed: 220 rpm
solution flow rate
regular scrub: 0.30 gal/min (1.1 l/min) or 100 minutes per solution tank – all models
heavy scrub: 0.60 gal/min (2.3 l/min) or 50 minutes per solution tank – all models
extreme scrub: 0.90 gal/min (3.4 l/min) or 33 minutes per solution tank – all models
squeegee width : 41.9 in (106 cm)
dimensions (w/o squeegee): w = 33 in (83 cm)l = 62.5 in (159 cm)h = 45 in (114 cm)
weight w/ std. batteries: 914 lb (415 kg)
weight w/ std. batteries: 914 lb (415 kg) 914 lb (415 kg) 946 lb (430 kg) 946 lb (430 kg)
voltage: 36 v – all models
power source: (6) 6 v batteries (wet acid and gel cell available) – all models
available chargers: 36 v, 20 amp free standing or 36 v, 21 amp onboard charger
solution control: precision-flow electric pump – axp (pulse control gravity feed - warrior st)
solution tank: 30 gal (114 l) – all models
recovery tank: 30 gal (114 l) – all models
scrub motors: (2) 0.75 hp (560 w) – all models
vacuum motor: 0.75 hp (560 w) 3-stage – all models
sound level: 69 db a with sound suppression kit or 71 db a standard – all models
drive system: 0.5 hp (375 w) variable forward and reverse, max speed = 3 mph (4.83 km/hr) – all models
gradeability: 16% transport, 5% scrubbing – all models
drive wheels: (2) 13 in (33 cm) dia. foam-filled, gray non-marking – all models
