True Vacuum Performance on a Rider Platform
The Advance VacRide puts you behind the wheel of the first rider-vacuum with true vacuum performance. The VacRide's dual motors and HEPA filter provide better dirt pickup and filtration than carpet sweepers and other rider vacuums. In addition, you'll save time (and your back !) while cleaning large carpeted areas compared to traditional wide area vacuums.

True Vacuum Performance
•Dual HEPA filters protect indoor air quality (IAQ)
•Dual vacuum motors provide superior suction and dirt pickup
•Dual brushes thoroughly clean all types of carpet

Productive Rider Platform
•Comfortable rider platform reduces operator fatigue
•Standard "quiet mode" is at 64 dBA for quiet daytime cleaning without disturbing occupants
•28 inch vacuum deck with standard side broom and 34 inch cleaning path provides better productivity than a standard wide-area vacuum
•Standard detailing wand offers the ability to clean baseboards and overhead without leaving the operator compartment

Vacuuming large, carpeted areas doesn't have to be a mountain to climb. The Advance VacRide gets the job done faster, reduces operator fatigue and provides unmatched vacuum performance on a rider platform.

Brush Type Dual Cylindrical
Brush Length 28 in (71 cm)
Side Broom 10.5 in (27 cm)
Cleaning Path 34 in (86 cm)
Sound Pressure Level (IEC 60704-1) 67.0 dB A / 64.0 dB A (Quiet Mode)
Maximum Transport Speed 3.9 mph (6.3 kph)
Maximum Cleaning Speed 3.1 mph (4.8 kph)
Maximum Coverage per hour 46,675 ft2 (4,336 m2 )
Vacuum Motor 1 438 W, single stage, 25 H2O, 140 cfm
Vacuum Motor 2 560 W, three stage, 70 H2O, 66 cfm
Drive Motor 1.05 hp (780 W)
Brush Motor 1 0.5 hp (373 W), 1,500 rpm
Brush Motor 2 0.5 hp (373 W), 1,500 rpm
Filter Bag Dual layer, grade E50M, 7.8 gal
Final Filter Dual sealed H.E.P.A.
Machine Dimensions Length 52.25 in (132.7 cm) / Width 31.75 in (80.6 cm) / Height 51.25 in (130.2 cm)
Turning Radius 63.5 in (161 cm)
Machine Weight 536 lb (244 kg) without batteries 1,026 lb (465 kg) with 420 Ah batteries 1,400 lb (635 kg) Max shipping weight
