Benefits of SW4000 Rider Sweepers The SW4000 is designed to improve productivity, simplify operation and minimize downtime to reduce your Total Cost of Ownership. Equipped with a safe and efficient retractable hopper and hydraulic high dump — which easily deposits into a standard dumper — you’ll have a floor sweeping solution that gets more done in less time.
-Simplify operation and maximize efficiency with our Clear-View™ design, plus One-Touch™ controls and drive pedal to activate/deactivate all sweeping functions
-Maneuver in tight corners and narrow aisles with intuitive front wheel steering and front wheel drive
-Invest in a sweeper that’s built to last — retractable spring-loaded side brooms, rugged steel guards, foam filled wheels and robust polyethylene covers
-Deliver superior dust control with the optional DustGuard™ [4.7 Innovations] misting system
-Expedite service and repair with MaxAccess™ interlocking compartments and tool-less broom and filter removal
Productivity - maximum ft²/h (m²/h): 94,200 ft2/hr (8,750 m2/hr)
Cleaning path - Dual Side Broom: 49 in (125 cm)
Main broom sweep path: 28 in (70 cm)
Side broom diameter: (2) 18 in (45 cm)
Debris hopper volume: 2.6 cu ft (75 L)
Debris hopper weight: 220 lb (100 kg)
Debris hopper dump height: 63 in (159 cm)
Dust filter: 75 sq ft (7 sq m)
DustGuard™ Tank Capacity (optional): 5.3 gal (20 L)
Stage 1 Dust: Guard™ (optional)Side broom "fog" system for fugitive dust control
Stage 2 Vacuumized Main Broom Chamber: Captures dust from the main broom
Stage 3 Ultra-Web® Nanofiber Filter: >98% efficient on 0.3 - 1.0 micron particles
Stage 4 Airflow Restoration System: Liberator™ aggressive, multi frequency vibration filter shaker
Length x width x height (excluding side brooms): 65 x 41 x 52 in (164 x 104 x 133 cm)
Height with overhead guard in. (cm): 78 in (199 cm)
Max. travel speed: 4.3 mph (7 km/hr)
Max. gradeability (working): 20% (11.3 deg)
Batteries: 24 Volt, 310 Ah C20
Weight with batteries - GVW: 2,215 lb (1,005 kg)
Weight with batteries - Empty: 1,648 lb (749 kg)
Sound level: 65 dB A
Min. aisle turn (cm): 76 in (192 cm)
Nilfisk-Advance SW4000 Parts and Support
Maximize Performance, Minimize Costs The SW4000™ Rider Sweeper maximizes performance and reliability, and comes equipped with a safe and efficient hydraulic high dump for use in warehouses, schools, shopping malls, parking lots, sport centers, recycling facilities and more.
Benefits of SW4000 Rider Sweepers The SW4000 is designed to improve productivity, simplify operation and minimize downtime to reduce your Total Cost of Ownership. Equipped with a safe and efficient retractable hopper and hydraulic high dump — which easily deposits into a standard dumper — you’ll have a floor sweeping solution that gets more done in less time.
-Simplify operation and maximize efficiency with our Clear-View™ design, plus One-Touch™ controls and drive pedal to activate/deactivate all sweeping functions
-Maneuver in tight corners and narrow aisles with intuitive front wheel steering and front wheel drive
-Invest in a sweeper that’s built to last — retractable spring-loaded side brooms, rugged steel guards, foam filled wheels and robust polyethylene covers
-Deliver superior dust control with the optional DustGuard™ [4.7 Innovations] misting system
-Expedite service and repair with MaxAccess™ interlocking compartments and tool-less broom and filter removal
Productivity - maximum ft²/h (m²/h): 94,200 ft2/hr (8,750 m2/hr)
Cleaning path - Dual Side Broom: 49 in (125 cm)
Main broom sweep path: 28 in (70 cm)
Side broom diameter: (2) 18 in (45 cm)
Debris hopper volume: 2.6 cu ft (75 L)
Debris hopper weight: 220 lb (100 kg)
Debris hopper dump height: 63 in (159 cm)
Dust filter: 75 sq ft (7 sq m)
DustGuard™ Tank Capacity (optional): 5.3 gal (20 L)
Stage 1 Dust: Guard™ (optional)Side broom "fog" system for fugitive dust control
Stage 2 Vacuumized Main Broom Chamber: Captures dust from the main broom
Stage 3 Ultra-Web® Nanofiber Filter: >98% efficient on 0.3 - 1.0 micron particles
Stage 4 Airflow Restoration System: Liberator™ aggressive, multi frequency vibration filter shaker
Length x width x height (excluding side brooms): 65 x 41 x 52 in (164 x 104 x 133 cm)
Height with overhead guard in. (cm): 78 in (199 cm)
Max. travel speed: 4.3 mph (7 km/hr)
Max. gradeability (working): 20% (11.3 deg)
Batteries: 24 Volt, 310 Ah C20
Weight with batteries - GVW: 2,215 lb (1,005 kg)
Weight with batteries - Empty: 1,648 lb (749 kg)
Sound level: 65 dB A
Min. aisle turn (cm): 76 in (192 cm)
Benefits of SW4000 Rider Sweepers The SW4000 is designed to improve productivity, simplify operation and minimize downtime to reduce your Total Cost of Ownership. Equipped with a safe and efficient retractable hopper and hydraulic high dump — which easily deposits into a standard dumper — you’ll have a floor sweeping solution that gets more done in less time.
-Simplify operation and maximize efficiency with our Clear-View™ design, plus One-Touch™ controls and drive pedal to activate/deactivate all sweeping functions
-Maneuver in tight corners and narrow aisles with intuitive front wheel steering and front wheel drive
-Invest in a sweeper that’s built to last — retractable spring-loaded side brooms, rugged steel guards, foam filled wheels and robust polyethylene covers
-Deliver superior dust control with the optional DustGuard™ [4.7 Innovations] misting system
-Expedite service and repair with MaxAccess™ interlocking compartments and tool-less broom and filter removal
Productivity - maximum ft²/h (m²/h): 94,200 ft2/hr (8,750 m2/hr)
Cleaning path - Dual Side Broom: 49 in (125 cm)
Main broom sweep path: 28 in (70 cm)
Side broom diameter: (2) 18 in (45 cm)
Debris hopper volume: 2.6 cu ft (75 L)
Debris hopper weight: 220 lb (100 kg)
Debris hopper dump height: 63 in (159 cm)
Dust filter: 75 sq ft (7 sq m)
DustGuard™ Tank Capacity (optional): 5.3 gal (20 L)
Stage 1 Dust: Guard™ (optional)Side broom "fog" system for fugitive dust control
Stage 2 Vacuumized Main Broom Chamber: Captures dust from the main broom
Stage 3 Ultra-Web® Nanofiber Filter: >98% efficient on 0.3 - 1.0 micron particles
Stage 4 Airflow Restoration System: Liberator™ aggressive, multi frequency vibration filter shaker
Length x width x height (excluding side brooms): 65 x 41 x 52 in (164 x 104 x 133 cm)
Height with overhead guard in. (cm): 78 in (199 cm)
Max. travel speed: 4.3 mph (7 km/hr)
Max. gradeability (working): 20% (11.3 deg)
Batteries: 24 Volt, 310 Ah C20
Weight with batteries - GVW: 2,215 lb (1,005 kg)
Weight with batteries - Empty: 1,648 lb (749 kg)
Sound level: 65 dB A
Min. aisle turn (cm): 76 in (192 cm)
Parts
Can't find what you need? Click here or call 1-800-USA-CLEAN
Need a professional? We offer in person service.
Learn more
Diagrams
- View all diagrams
- - Batteries, Brushes, and Charger
- - Commonly Asked For Parts
- - Frequently Replaced Parts
- Accelerator Pedal Assembly
- Accessories Assembly
- Batteries Assembly
- Brake Pedal Assembly
- Broom Assembly
- Broom Cover Assembly
- Broom Levers Assembly
- Control Panel Assembly
- Control Panel Cover Assembly
- Electric System Assembly - Before SN 3810162100038
- Electric System Assembly - After SN 381016210037
- Electric Wheel Assembly
- Extensible Arm Assembly
- Floor Mat and Beacon Assembly
- Frame Assembly - 1
- Frame Assembly - 2
- Frame System Assembly - Lower
- Frame System Assembly - Upper
- Front Lift Flap Assembly
- Front Light, Seatbelt, and Armrest Assembly
- Hopper Assembly
- Hydraulic Assembly
- Lateral Covers Assembly
- Lifting Arms Assembly
- Main Broom Adjustment Assembly
- Main Broom Assembly
- Motor Wheel Assembly
- Overhead Guard and Canopy Assembly
- Panel Filter Assembly
- Seat Cover Assembly
- Side Broom Guard Assembly
- Steering Column Assembly
- Vacuum System Assembly
- Wiring Diagram
