Versatile cleaning and stripping systems designed for significant time and labor savings.

The enhanced Advance Sprite 16 is the wet/dry tank vacuum that cleans and saves. Saves money, that is. Don't waste expensive time and labor on mops and buckets. For powerful, simple, quiet and efficient cleaning, put the Sprite 16 to work on your floors. New features include a clear cover to allow workers to see the water anc chemical level in the tank, and a short pigtail cord attaches to your 50 foot cable, eliminating the need to wrap a long cord around the machine between uses.

Dependable Design
The Advance Sprite 16 consist of a powerful, yet quiet, 70 dBA, 1.3 hp 2-stage, by-pass motor, located under the tank for protection from water and debris. The tank holds 16 gallons and is constructed of rugged and corrosion-resistant polyethylene material. The tank conveniently pivots on a hinge to dump contents, or drain through a built-in hose. The entire tank lifts off for cleaning and allows total access for motor service or maintenance.

Wet Pick-up
Sprite 16 picks up water faster than machines featuring a hose and wand, effectively cleaning- even in tight spots. The 24 inch front-mounted chemical resistant squeegee maneuvers right up to walls and into corners, picking up water and debris in both forward and reverse motion, A simple-to-use floor pedal raises or lowers the squeegee, making it transport a snap. A float system stops recovery to prevent tank overflow.

Motor 1.3 hp, 115 V / 60 Hz, 2 stage
Air Flow 91 ft3 /min (2,577 L/min)
Sealed Water Lift 88 in (223 cm)
Sound Level 70 dB A
Construction Roto-molded polyethylene tank
Tank Capacity 16 gal (60 L) actual working
Squeegee Width 24 in (61 cm), optional 30 in (76 cm)
Squeegee Pick-up Rate 11,500 ft2 /hr (1,068 m2 /hr)
Power Cable 50 ft (15 m) detachable
Wheels 10 in x 1.75 in (25 cm x 4.5 cm) rear 4 in x 1 in (10 cm x 2.5 cm) front casters
Dimensions Height (Dome) 35 in (89 cm) Height (Handle) 39.5 in (100 cm) Width 17 in (43 cm) Length 40.5 in (103 cm)
Net Weight 77 lb (35 kg)
Shipping Weight 85 lb (39 kg)
