SC500

33

• Parts
• Diagrams
• Manuals
• Bulletins

From hospitals and schools, to sports centers and manufacturing floors, the Advance SC500 walk-behind scrubber ushers in a new wave of productivity in the places where cleaning professionals need it most. With a modern design engineered to provide better control and improved sightlines, this compact 20 in and 12 gallon disc or orbital scrubber cleans both effectively and quietly. Already one of the quietest compact scrubbers, the SC500 has a Quiet Mode for daytime cleaning environments.

Efficiency revitalized.
With a revolutionary flow regulation system that adjusts the solution output based on the speed of the machine, SC500 ensures consistent cleaning results using less water and chemical while improving productivity per tank. Combine that with the exclusive EcoFlex system- which allows for variable detergent (including ultra-low) or water-only cleaning-- and the SC500 is in a category of its own when it comes to sustainability and efficient cleaning.

Ergonomically inclined.
The extremely maneuverable SC500 features a low center of gravity and an easily accessible variable speed, pressure sensitive control paddle. THat means virtually anyone can control the SC500's traction drive system, effortlessly propelling it forward at whatever speed feels comfortable and appropriate for the cleaning application.

Ease of use maximized
Every facet of the SC500 has been fine-tuned for an optimal user experience. The unique multi-function display and control panel grants managers- using the yellow Superuser key- access to adjustable cleaning parameters. Operators- using the gray key- are able to start cleaning at the beginning of their shift. They don't need to take the time to change machine settings before they start.

Scrub Path 20 in (50.8 cm)
Batteries 130 Ah Wet / 140 Ah AGM
Battery Count 2
Solution Tank 12 gal (45 L)
Recovery Tank 12 gal (45 L)
Brush Speed 155 RPM
Brush Pressure 33 / 66 lb (15 / 30 kg)
Brush Motor(s) 450 W
Squeegee Width 26.5 in (67.3 cm)
Vacuum Motor 280 W
Waterlift / Airflow 29.9 in (76 cm) H2O
Vacuum Motor 100 CFM
Sound Level 60 dB A Silent / 63 dB A Normal
Drive Motor 200 W
Length 48.3 in (127.7 cm)
Width 20.9 in (72 cm)
Height 41.9 in (106.3 cm)
Weight (w/o Batteries) 187.4 lb (83 kg)
Onboard Charger Standard
Onboard Detergent EcoFlex System™ Standard
Traction Drive Standard
Variable Solution Flow Standard
Smart Key Standard
Orbital Scrubbing N/A
Multifunction Display Standard
Quiet Mode Standard
Productivity (Theoretical Max) 24,552 ft2 (2,280 m2 )
Run Time Continuous 3.5 Hours
