At the heart of the Micromax 20DC is a unique cylindrical scrub brush that can sweep and scrub in one pass. This dual multitasking function is ideal for light industrial or small manufacturing facilities where debris pickup is important. Unlike a disc brush, the cylindrical brush picks up large debris and deposits it into a hopper to prevent jamming the squeegee or vacuum hose. Just imagine the additional square footage you can clean by eliminating the need to pre-sweep or mop.

In keeping with the Total Clean philosophy, the Micromax allows complete and easy access to all machine components. Total clean features result in lower total cost of ownership and increased productivity to drive down the cost to clean.

Scrub Path 20 in (51 cm) 20 in (51 cm) Max Productivity Per Hour 22,000 ft2 (2,044 m2 ) 22,000 ft2 (2,044 m2 ) @ 2.5 mph/ 4 kph @ 2.5 mph/ 4 kph Scrub Deck Rotary Disc (tools-free inter- Dual Cylindrical Brush with Debris Hopper changeable disc/cylindrical) (tools-free interchangeable disc/cylindrical) Scrub Head(s) (1) 20 in (51 cm) disc (2) 4.33 in dia x 19 in (48 cm) cylindrical brushes Power Source (2) 12 V batteries 130 Ah wet (2) 12 V batteries 130 Ah wet or 98 Ah gel (onboard charger) or 98 Ah gel (onboard charger) Brush Speed 170 rpm 570 rpm Brush Pressure 65 lb (29.5 kg) 67 lb (31 kg) Brush Motor 0.68 hp (510 W) (2) 0.54 hp (400 W) Solution System Gravity feed, variable Gravity feed, variable w/ Smart Solutions™ w/ Smart Solutions™ Solution Tank 9.6 gal (36 L) 9.6 gal (36 L) Recovery Tank 9.6 gal (36 L) 9.6 gal (36 L) Vacuum Motor 0.51 hp (380 W) 0.51 hp (380 W) Sound Level 65 dB A 65 dB A Drive System Variable speed, forward drive Variable speed, forward drive up to 2.5 mph (4 kph) up to 2.5 mph (4 kph) Drive Motor 0.17 hp (130 W) 0.17 hp (130 W) Length 50 in (129 cm) - extended handle 48 in (122 cm) - extended handle Width (w/o squeegee) 20 in (51 cm) 23 in (59 cm) Height 34 in (86 cm) - top of tank 34 in (86 cm) - top of tank Squeegee Width 30.3 in (77 cm) 30.3 in (77 cm) Weight 360 lb (164 kg) w/ std batteries 370 lb (168 kg) w/ std batteries
