Make the move from mops to the faster, more thorough cleaning method of automatic scrubbing with the Micromatic 14E. This machine applies cleaning solution, scrub the floor, and then picks up the dirty solution, all in one pass. Leaves floors clean and dry, ready for immediate traffic.

With the 14E, an operator will be able to clean 1,000-1,600 square feet(100-150 m2) per tankful. Compare that coverage with mop and bucket cleaning, and remember- that's for a thorough scrubbing, not just mopping floor.

It's compact enough to get into narrow aisles and congested areas, and is the most maneuverable automatic scrubber of its kind. Turns in its own length, and won't leave solution on the floor. The cylindrical scrub brush cleans a 14 inch (34 cm) wide path, and works on nearly any surface, including grouted tile, marble, raised tile, resilient tile, concrete and ceramic, to name a few. The unique shroud/squeegee head shifts sideways, for cleaning under furniture and around obstacles in either direction. Cleans right up to walls, and the squeegee system picks up in both forward and reverse.

The Micromatic 14E is cord-electric, so it's ready to operate when and as long as you are. Simple controls make it easy to operate, and comfortable design make it easy on the operator as well.

Rugged construction assures the dependable Micromatic will stay on the job, but service and maintenance are inevitable. That's why it's designed for easy access to modular components, so maintenance down time will be minimal.

Check it out, and ask for a demonstration. You'll find the Micromatic 14E is not only a thoroughly efficient cleaning machine, bu economical and affordable as well.

Vacuum Motor: 1.2 hp (900 W)
Vacuum Airflow: 95 ft3 /min (45 L/sec)
Waterlift: 96 in sealed (24 kPa)
Power Cable: 40 ft (12 m) long
Recovery Tank: 3.2 gal (12 L)
Solution Tank: 3 gal (11 L)
Solution Control: High/low pre-set positions (adjustable)
Brush Motor: 0.4 hp (320 W)
Brush Data: 4 in (10 cm) diameter cylindrical roller, nylon bristles
Brush Pressure: 35 lb (16 kg) max
Brush Speed: 1,000 rpm
Squeegee: 17 in (44 cm) curved, dual blades for forward/reverse pick up
Cleaning Width: 14 in (34 cm)
Cleaning Rates*: 14,400 ft2 /hr (1,360 m2) theoretical
Sound Level: 68 dB A
Controls: Master on/off switch for vacuum and brush motor, indicator lights (includes power on for
vacuum and brush motors.)
Length: 25 in (62 cm) w/handle folded over
Width: 17 in (44 cm)
Height: 19 in (48 cm) base, 41 in (105 cm) with handle upright
Weight: 90 lb (41 kg)
