Ask our Team! The Advance Exterra is unsurpassed in indoor and outdoor power sweeping. A 50 inch main broom - the widest in this sweeper class - combined with full time dust controlled dual side brooms*, creates an incredible 77 inch sweep path.

On conventional machines, dust is controlled at the main broom and, the side brooms must be raised in open areas to prevent airborne fugitive dust. The Exterra is not a conventional machine. The innovative DustClear Five Stage Dust Control System allows for full time use of the dual side brooms by controlling dust along the entire sweep path - including the side brooms. Productivity is then increased by up to 71% compared with conventional sweepers that control dust only at the main broom.

With superior dust control, innovative safety features, low maintenance costs, and ease of operation, the Advance Exterra redefines power sweeping.

Sweeping System
Cleaning Path - Single Side Broom 65 in (165 cm) 65 in (165 cm)
Cleaning Path - Dual Side Brooms 77 in (196 cm) 77 in (196 cm)
Main Broom Length 50 in (127 cm) 50 in (127 cm)
Side Broom Diameter 24 in (61 cm) or 26 in (66 cm) 24 in (61 cm) or 26 in (66 cm)
Debris Hopper
Volume 14 ft3
(396 L) 14 ft3
(396 L)
Dump Height 60 in (152 cm) 60 in (152 cm)
DustClear™ Five Stage Dust Control System
Stage 1 DustGuard™ Side broom “fog” system 14 gal (53 L) Side broom “fog” system 14 gal (53 L)
Stage 2 Vacuumized Main Broom Chamber Captures all dust kicked up from the main broom Captures all dust kicked up from the main broom
Stage 3 Airflow Labyrinth Removes 90% of dust from the air stream Removes 90% of dust from the air stream
Stage 4 Ultra-Web® Nanofiber Filter >98% efficient on 0.3 - 1.0 micron particles >98% efficient on 0.3 - 1.0 micron particles
Stage 5 Airflow Restoration System Aggressive, full filter shake vibration Aggressive, full filter shake vibration
Power System
Engine
Gasoline/LP Kubota, 0.96 L, 31 hp GM, 1.6 L, 56 hp
Diesel Kubota, 1.5 L, 35.5 hp
Ramp Climbing
Transport 20% 11° 25% 14°
Sweeping 15% 8° 25% 14°
Dimensions
Tires
Front (2) 21 in (53 cm) pneumatic 21 in (53 cm) pneumatic
Rear 18 in (46 cm) pneumatic 18 in (46 cm) pneumatic
Aisle U-turn (left) 109 in (277 cm) 109 in (277 cm)
Length 94 in (239 cm) 94 in (239 cm)
Width 64 in (163 cm) 64 in (163 cm)
Height without OHG 58 in (147 cm) 58 in (147 cm)
Height with OHG 82 in (208 cm) 82 in (208 cm)
Height with Cab 79 in (201 cm) 79 in (201 cm)
Net Weight 2,700 lb (1,225 kg) 2,700 lb (1,225 kg)
Sound Level 81 dB A at operator’s position 83 dB A at operator’s position

EXTERRA

Interested in purchasing equipment?

Contact our Experts

Need help finding a part?

Ask our Team!
The Advance Exterra is unsurpassed in indoor and outdoor power sweeping. A 50 inch main broom - the widest in this sweeper class - combined with full time dust controlled dual side brooms*, creates an incredible 77 inch sweep path.

On conventional machines, dust is controlled at the main broom and, the side brooms must be raised in open areas to prevent airborne fugitive dust. The Exterra is not a conventional machine. The innovative DustClear Five Stage Dust Control System allows for full time use of the dual side brooms by controlling dust along the entire sweep path - including the side brooms. Productivity is then increased by up to 71% compared with conventional sweepers that control dust only at the main broom.

With superior dust control, innovative safety features, low maintenance costs, and ease of operation, the Advance Exterra redefines power sweeping.

Sweeping System
Cleaning Path - Single Side Broom 65 in (165 cm) 65 in (165 cm)
Cleaning Path - Dual Side Brooms 77 in (196 cm) 77 in (196 cm)
Main Broom Length 50 in (127 cm) 50 in (127 cm)
Side Broom Diameter 24 in (61 cm) or 26 in (66 cm) 24 in (61 cm) or 26 in (66 cm)
Debris Hopper
Volume 14 ft3
(396 L) 14 ft3
(396 L)
Dump Height 60 in (152 cm) 60 in (152 cm)
DustClear™ Five Stage Dust Control System
Stage 1 DustGuard™ Side broom “fog” system 14 gal (53 L) Side broom “fog” system 14 gal (53 L)
Stage 2 Vacuumized Main Broom Chamber Captures all dust kicked up from the main broom Captures all dust kicked up from the main broom
Stage 3 Airflow Labyrinth Removes 90% of dust from the air stream Removes 90% of dust from the air stream
Stage 4 Ultra-Web® Nanofiber Filter >98% efficient on 0.3 - 1.0 micron particles >98% efficient on 0.3 - 1.0 micron particles
Stage 5 Airflow Restoration System Aggressive, full filter shake vibration Aggressive, full filter shake vibration
Power System
Engine
Gasoline/LP Kubota, 0.96 L, 31 hp GM, 1.6 L, 56 hp
Diesel Kubota, 1.5 L, 35.5 hp
Ramp Climbing
Transport 20% 11° 25% 14°
Sweeping 15% 8° 25% 14°
Dimensions
Tires
Front (2) 21 in (53 cm) pneumatic 21 in (53 cm) pneumatic
Rear 18 in (46 cm) pneumatic 18 in (46 cm) pneumatic
Aisle U-turn (left) 109 in (277 cm) 109 in (277 cm)
Length 94 in (239 cm) 94 in (239 cm)
Width 64 in (163 cm) 64 in (163 cm)
Height without OHG 58 in (147 cm) 58 in (147 cm)
Height with OHG 82 in (208 cm) 82 in (208 cm)
Height with Cab 79 in (201 cm) 79 in (201 cm)
Net Weight 2,700 lb (1,225 kg) 2,700 lb (1,225 kg)
Sound Level 81 dB A at operator’s position 83 dB A at operator’s position

Nilfisk-Advance EXTERRA Parts and Support

The Advance Exterra is unsurpassed in indoor and outdoor power sweeping. A 50 inch main broom - the widest in this sweeper class - combined with full time dust controlled dual side brooms*, creates an incredible 77 inch sweep path.

On conventional machines, dust is controlled at the main broom and, the side brooms must be raised in open areas to prevent airborne fugitive dust. The Exterra is not a conventional machine. The innovative DustClear Five Stage Dust Control System allows for full time use of the dual side brooms by controlling dust along the entire sweep path - including the side brooms. Productivity is then increased by up to 71% compared with conventional sweepers that control dust only at the main broom.

With superior dust control, innovative safety features, low maintenance costs, and ease of operation, the Advance Exterra redefines power sweeping.

Sweeping System
Cleaning Path - Single Side Broom 65 in (165 cm) 65 in (165 cm)
Cleaning Path - Dual Side Brooms 77 in (196 cm) 77 in (196 cm)
Main Broom Length 50 in (127 cm) 50 in (127 cm)
Side Broom Diameter 24 in (61 cm) or 26 in (66 cm) 24 in (61 cm) or 26 in (66 cm)
Debris Hopper
Volume 14 ft3
(396 L) 14 ft3
(396 L)
Dump Height 60 in (152 cm) 60 in (152 cm)
DustClear™ Five Stage Dust Control System
Stage 1 DustGuard™ Side broom “fog” system 14 gal (53 L) Side broom “fog” system 14 gal (53 L)
Stage 2 Vacuumized Main Broom Chamber Captures all dust kicked up from the main broom Captures all dust kicked up from the main broom
Stage 3 Airflow Labyrinth Removes 90% of dust from the air stream Removes 90% of dust from the air stream
Stage 4 Ultra-Web® Nanofiber Filter >98% efficient on 0.3 - 1.0 micron particles >98% efficient on 0.3 - 1.0 micron particles
Stage 5 Airflow Restoration System Aggressive, full filter shake vibration Aggressive, full filter shake vibration
Power System
Engine
Gasoline/LP Kubota, 0.96 L, 31 hp GM, 1.6 L, 56 hp
Diesel Kubota, 1.5 L, 35.5 hp
Ramp Climbing
Transport 20% 11° 25% 14°
Sweeping 15% 8° 25% 14°
Dimensions
Tires
Front (2) 21 in (53 cm) pneumatic 21 in (53 cm) pneumatic
Rear 18 in (46 cm) pneumatic 18 in (46 cm) pneumatic
Aisle U-turn (left) 109 in (277 cm) 109 in (277 cm)
Length 94 in (239 cm) 94 in (239 cm)
Width 64 in (163 cm) 64 in (163 cm)
Height without OHG 58 in (147 cm) 58 in (147 cm)
Height with OHG 82 in (208 cm) 82 in (208 cm)
Height with Cab 79 in (201 cm) 79 in (201 cm)
Net Weight 2,700 lb (1,225 kg) 2,700 lb (1,225 kg)
Sound Level 81 dB A at operator’s position 83 dB A at operator’s position

Parts

  • Product
  • Qty in Cart
  • Quantity
  • Price
  • Subtotal
  • OEM
    56507417 - Door flap 372-2478

    Door flap 372-2478

    $27.64
    $27.64
    Qty in Cart: 0
    Price:
    $27.64
    Subtotal:
  • OEM
    56508083 - Hopper flap 372-2321

    Hopper flap 372-2321

    $192.00
    $192.00
    Qty in Cart: 0
    Price:
    $192.00
    Subtotal:
  • OEM
    56507725 - Regulator 372-2135

    Regulator 372-2135

    $1,990.97
    $1,990.97
    Qty in Cart: 0
    Price:
    $1,990.97
    Subtotal:
  • OEM
    305053 - Proximity sensor 272-8850

    Proximity sensor 272-8850

    $169.11
    $169.11
    Qty in Cart: 0
    Price:
    $169.11
    Subtotal:
  • OEM
    369675 - Female coupler 272-7275

    Female coupler 272-7275

    $40.08
    $40.08
    Qty in Cart: 0
    Price:
    $40.08
    Subtotal:
  • OEM
    900003 - Connector 272-3170

    Connector 272-3170

    $13.17
    $13.17
    Qty in Cart: 0
    Price:
    $13.17
    Subtotal:
  • OEM
    418897 - Impeller 272-3096

    Impeller 272-3096

    $116.47
    $116.47
    Qty in Cart: 0
    Price:
    $116.47
    Subtotal:
  • ships same day
    OEM
    56507350 - Polypropylene side broom 372-2503

    Polypropylene side broom 372-2503

    $192.00
    Matches:50735056507350572-06658801297088055920May fit on these models - select model and diagram to confirmNilfisk-Advance EXTERRANilfisk-Advance SW8000
    $192.00
    Qty in Cart: 0
    Price:
    $192.00
    Subtotal:
