The Advance Advenger® family of rider scrubbers combines versatility, productivity and sustainability all in one efficient platform. With three unique models available—disc, cylindrical and REV™, you can select the right machine for your daily scrubbing challenges.

For deep scrubbing needs, the Advenger REV can also remove floor finish in a single pass. Advenger rider scrubbers are designed for maximum efficiency with Advance’s EcoFlex™ onboard detergent-dispensing system, which allows users to effectively match scrubbing performance to the average soil content on the floor.

Clean green and still meet the highest expectations for clean floors with the standard, onboard EcoFlex System. The EcoFlex System controls the consumption of water, detergent and energy so effectively that real savings can be gained without compromising performance. Effortlessly switch between water-only cleaning or various cleaning intensities to match cleaning performance to the soil on the floor and the required level of clean. More soil? No problem. Activate the “burst of power” for extra cleaning performance and easily return to the original settings for minimum usage of water, detergent and power.

Designed with the operator in mind, the Advenger family of scrubbers features an open layout to allow easy access to the rider compartment while also providing excellent sight lines to the floor. Tight, yet easily maneuverable, steering enables scrubbing in compact or hard-to-reach areas. For enhanced safety, Advenger scrubbers are NFSI-certified to aid in the prevention of slips and falls.

Attack your daily and deep scrubbing applications with the Advenger REV. Employing a wide 28 inch scrub path and our exclusive patented REV Technology Random Orbital Scrubbing technology, the Advenger REV scrubs deeper and more uniformly to leave a perfectly scrubbed surface with no swirl marks while using far less water and chemicals. When the job calls for a deeper scrub, operators can switch to floor finish removal with a touch of a button. Using only water, the Advenger REV leaves floors ready for restoration in a single pass. Better, more efficient scrubbing with significantly less time and labor.

-EcoFlex™ System: Effortlessly switch between water-only cleaning or different cleaning intensities. Reduce chemical usage, labor costs, and environmental impact
-Refillable detergent cartridge conserves cleaning solution while eliminating the need for pre-mixing
-Standard low-flow scrubbing mode conserves water usage by up to -70% while delivering high productivity per tankful
-High traction non-marking urethane tires
-Adjustable steering column easily configures to driver’s height

Scrub head type: Disc
Cleaning path: 28 in
Sound pressure level (dB(A)): 63.7 dB A (IEC 60704-1/ISO 11201)
Max. transport speed mph (km/h): 3.91 mph (6.3 kph)
Max. cleaning speed: 3.12 mph (4.8 kph)
Max. coverage per hour @ 3.12 MPH: 39,424 sq ft (3,663 sq m)
Solution tank capacity gal (l): 28 gal (106 L)
Recovery tank capacity gal (l): 29 gal (110 L)
Low flow rate: 0.33 gal/min (1.25 L/min)
Medium flow rate: 0.66 gal/min (2.50 L/min)
High flow rate: 1.0 gal /min (3.79 L/min)
Productivity per tankful: 85 mins (Scrubbing); N/A (Floor Finish Removal)
Power source: 24 VDC
Brush motor hp (W): 0.64 hp (480 W)
Brush speed (RPM): 260 RPM
Scrub pressure - regular scrub: 90 lb (39 kg)
Scrub pressure - heavy scrub: 150 lb (65 kg)
Scrub pressure - extreme scrub: 220 lb (96 kg)
Drive motor hp (W): 1.05 hp (780 W)
Vacuum motor: 0.75 hp (560 W)
Sealed waterlift: 63 in H2O (15.7 kPa)
Max. airflow rate (cfm): 66 @ 2 in (5 cm) orifice
Min. aisle turn (cm): 63 in (160 cm)
Body length: 60 in (152 cm)
Body height: 51.7 in (131 cm)
Body width: 27.5 in (70 cm)
Max. width w/o squeegee: 31 in (79 cm)
Squeegee width: 32.6 in (83 cm)
Max. weight w/o batteries: 536 lb (244 kg)
Max. weight (full solution tank and largest batteries): 1,451 lb (658 kg)
Max. shipping weight: 1,400 lb (635 kg)
Gradeability transport % (DEG): 16% (9 degrees)
Gradeability - Cleaning: 9% (5 degrees)
Max. PSI: 175 PSI (12.3 kg/sq cm); (Full tank and 200 lb rider)
