The AdSpray™ pressure washers blast away dirt and grime for fast and efficient cleaning. Fast because they power clean… efficient because the chemical reaches areas you can't. Chemical is sprayed on with low pressure, then dirt is blasted off with high-pressure power.

The AdSpray™ 1500A is a hand-carried model with adjustable pressure to 1500 psi (103 bar) for various applications.

The spray gun has trigger on/off spray control, and is at the end of a 26 foot (8 m) long hose. Nozzle tip turns to vary the spray pattern from zero to sixty degrees.

Motor/Engine Two horsepower, 115 V / 60 Hz
Power Cord 6 ft (2 m) long, with ground fault interrupter
Pump Teflon graphite seals, ceramic coated steel pistons, stainless steel valves, aluminum head, mechanical thermal relief valve, ceramic plunger, and by-pass running against closed gun.
Output Adjustable, to 1,500 psi (103 bar), at - 2.1 gpm (8 L/min)
Chemical Injection Variable rate, after the pump
Gun Two-piece 36 in (91 cm) w/ 0-60° adjustable spray nozzle, trigger on/off spray control and plastic insulation
Hose 26 ft (8 m)
Dimensions Height 9 in (23 cm) Width 9 in (23 cm) Length 15.5 in (39 cm
Net Weight 50 lb (22.7 kg)
Shipping Weight 57 lb (26 kg)
